神钢零件查询(BREAKER) - NIBBLER/BREAKER ATTACHMENT - SK70SR-1E/SK70SR-1ES ASN YT04-07001 (9/04-) (01-046[01]) - HARNESS ASSY, UPP (HAND CONTROL) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
909 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT13E00029F1 | [1] | HARNESS ASSY, UPP | |
| 1. | YT13E01094P1 | [1] | WIRE HARNESS | SMHARNESS |
| 2. | PY01P01043D7 | [1] | CABLE TIE,4.80mm W x 445mm L | KOBWire Ties -- 445mm Long |
| 3. | PY01P01043D4 | [1] | CABLE TIE,4.80mm W x 251mm L | KOBWire Ties -- 249mm Long |
| 4. | YX14E01004P1 | [2] | GROMMET | KOB |
| A1. | NA | [1] | NOT SERVICED | FORSCHEMATIC, ELEC (NOT IN SERVICE) |
