神钢零件查询(CLAMSHELL) - ATTACHMENT - SK200 EXCAVATORS (1/91-12/97) (011-60) - REWORK, UPP FRAME 2422N994 , D1, D2, D3 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
816 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2422N994 | [1] | REWORK, UPP FRAME | |
| 1. | 2416P16050 | [1] | BRACKET | BRACKET |
| 2. | 2416T24691 | [1] | BRACKET | BRACKET |
| . . | 2422N994D1 | [1] | REWORK, UPP FRAME | |
| 3. | 2418T22009 | [1] | SUPPORT | KOBPLATE |
| . . | 2422N994D2 | [1] | REWORK, UPP FRAME | |
| 4. | 2416T23351 | [1] | SUPPORT | KOB |
| . . | 2422N994D3 | [1] | REWORK, UPP FRAME | |
| 5. | ZS11C12020 | [1] | SCREW,Hex, M12 x 20mm, Cl 4.8 | KOBM12x1.75x20mm |
