神钢零件查询(CLAMSHELL) - ATTACHMENT - SK200 EXCAVATORS (1/91-12/97) (131-64) - REWORK, HYDR LINES, UPP TELESCOPIC, L.M.C. 24100J12145F1 & F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
191 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 2418P24474 | [1] | TUBE | |
| 3. | 2418P23938 | [1] | TUBE | |
| 4. | 2418T22275 | [1] | RIGID TUBE | KOBTUBE |
| 5. | 2418P22801 | [1] | RIGID TUBE | KOBTUBE |
| 6. | 2444Z3560D1 | [1] | FLEXIBLE HOSE | KOB |
| 7. | 2432T2326 | [2] | CLAMP | KOB |
| 8. | 2432T4355 | [2] | CLAMP | KOB |
| 9. | ZS13C12130 | [2] | SCREW | KOBM12x1.75x130mm Superseded by part number: ZS18C12130 |
| 10. | ZS13C12055 | [3] | SCREW | KOBM12x1.75x55mm Superseded by part number: ZS18C12055 |
| 11. | ZS13C12045 | [4] | SCREW | KOBM12x1.75x45mm Superseded by part number: ZS18C12045 |
| 12. | ZS23C10030 | [4] | SCREW,Hex Socket Head, M10 x 30mm | KOBM10x1.50x30mm Superseded by part number: ZS28C10030 |
| 13. | 2436U1197F2 | [1] | CONTROL VALVE | KOB |
| 14. | 2416P12072 | [1] | U-BRACKET | KOB |
| 15. | ZN13C12010 | [3] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 16. | ZW22X12000 | [7] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 17. | ZW22K10000 | [4] | LOCK WASHER | KOBLock -- ID 10.2 x OD 15.7 x Th 2.5mm |
| 18. | ZA33F28016 | [2] | ELBOW | KOB |
| 19. | ZA23F22012 | [2] | HYD CONNECTOR | KOB3/4"PF - M30x1.50 x 46mm Long |
| 20. | ZE12X20000 | [2] | CLAMP | KOB |
| 21. | ZA23B22000 | [1] | HYD CONNECTOR | KOBM30x1.50x38mm Long |
| 22. | ZD12P02900 | [2] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 23. | ZD12P02400 | [2] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 24. | 2444Z3554 | [1] | TEE | KOB |
| 25. | ZD12P03800 | [1] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| 26. | 2432P1082 | [1] | LABEL | KOBLABEL, Remarks: (FOR JAPAN) Superseded by part number: YT20T01033P1 |
| 28. | 2414T4875F1 | [1] | COVER | KOBCOVER ASSY |
| 28-1. | 2414P8059 | [1] | COVER | |
| 28-2. | 2427Z1454 | [1] | INSULATION, SOUND | |
