| . . | 24100J6677F3 | [1] | BOOM ASSY, 3.15M, Remarks: (Y Q) | |
| 1. | 2412J785F1 | [1] | BOOM FR. | |
| 1-29. | B05T0009C2 | [2] | BUSHING | KOB |
| 3. | 2418P18020D1 | [1] | TUBE | |
| 4. | 2418P18020D2 | [1] | TUBE | |
| 5. | 2418T12132 | [1] | RIGID TUBE | KOB Superseded by part number: 2418P22218 |
| 8. | ZH22Z04000 | [3] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 9. | ZG91S02000 | [2] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 10. | ZC26X28014 | [4] | CLAMP | KOBSingle Line -- 75x37x38mm (Ø28mm) |
| 11. | 2420R349D12 | [2] | HOSE | KOB Superseded by part number: HX21E04280DX |
| 12. | ZC47X10009 | [3] | CLIP | KOB Superseded by part number: ZC48X10009 |
| 13. | 2419T3852 | [1] | PIN | KOB |
| 14. | 2419T3360D3 | [1] | PIN | |
| 15. | 2419P1708D3 | [1] | PIN | |
| 16. | 2420T4004D1 | [1] | SCREW,M16 x 2 x 150mm | KOBM16x2.0x150mm |
| 17. | ZS13C16130 | [1] | SCREW | KOB |
| 18. | ZS13C12055 | [4] | SCREW | KOBM12x1.75x55mm Superseded by part number: ZS18C12055 |
| 19. | ZS13C12090 | [8] | SCREW | KOBM12x1.75x90mm Superseded by part number: ZS18C12090 |
| 20. | ZH32Z04000 | [1] | ELBOW | KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100) |
| 21. | ZN13C16013 | [4] | NUT | KOBM16x2.0mm |
| 23. | ZW22X12000 | [14] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 25. | ZW22X06000 | [3] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 26. | ZW26X06000 | [1] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 27. | ZW11X06000 | [3] | WASHER | KOBID 06.6 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 28. | ZD12P03400 | [2] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 29. | 2445R220D4 | [2] | SEAL,78.7mm ID x 95mm OD x 5mm Thk | KOBDust -- ID 80 X OD 95 x Th 5mm Superseded by part number: 84499640 |
| 30. | 2432T2363 | [1] | CLAMP | KOB Superseded by part number: YN42H01078P1 |
| 31. | ZS13C12065 | [1] | SCREW | KOBM12x1.75x65mm Superseded by part number: ZS18C12065 |
| 32. | 2432Z270 | [1] | CLAMP | KOB |
| 33. | ZN18C06005 | [4] | NUT | KOBM06x1.0mm |
| 35. | ZW22X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 36. | ZS13C10018 | [1] | SCREW | KOBM10x1.50x18mm |
| 37. | 2416T13056 | [1] | BRACKET | KOB |
| 38. | 2420Z1047 | [1] | SLOTTED NUT | KOBM56x5.5mm Castle |
| 39. | ZP15D08100 | [1] | SPRING | KOBCotter -- OD 08 x 100mm Long |
| 40. | 2418Z715 | [1] | WASHER | KOBID 58 x OD 105 x Th 9.0mm |
| 43. | ZG91U02000 | [1] | LUBE NIPPLE | KOB90° x 1/8" PT |
| 44. | 2438U1108F1 | [1] | CYLINDER | KOB(F2 ONLY), Remarks: SEE (C.P.M) |
| 45. | 2438U1104F1 | [1] | CYLINDER | KOB(F3 ONLY), Remarks: SEE (C.P.M) Superseded by part number: 2438U1108F1, 2418P22219D1 |
| 46. | 2432P2182 | [1] | NAME-PLATE (R.H) | |
| 47. | 2432P2181 | [1] | NAME-PLATE (L.H) | |
| 48. | ZX56T16150 | [2] | HOSE | |
| 49. | ZX56T12150 | [2] | HOSE | |
| 50. | 2418P21314 | [1] | TUBE (F2 ONLY) | |
| 51. | 2418P21314D2 | [1] | TUBE (F3 ONLY) | TUBE (F3 ONLY) |
