| . . | YY32H00003F2 | [1] | LINE | KOB |
| 1. | YX32H01015P1 | [1] | TUBE | KOB |
| 2. | YX32H01005P1 | [1] | TUBE | KOB |
| 4. | HH25R12012G6 | [1] | ELEC CONNECTOR | KOB |
| 4-1. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 5. | 2444Z2760 | [2] | HYD CONNECTOR | KOB1" PFx56.5mm Long (Incls. O-Ring ZD12P02900) |
| 5-1. | ZD12P02900 | [1] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 6. | ZH32X08000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 1/2", O-Ring | KOBElbow, 90° -- 1/2"PT (Incls. O-Ring ZD12P01800) |
| 6-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 7. | ZH32X12000 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 3/4", O-Ring | KOBElbow, 90° -- 3/4 PF (Incls. O-Ring 237-6012) |
| 7-1. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 8. | HH35X16016G1 | [2] | 90 ELBOW | KOB90° -- (Incls. O-Ring ZD12P02900) |
| 8-1. | ZD12P02900 | [1] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 9. | YN20M01046DC | [1] | PROTECTIVE SLEEVE,22.10mm ID x 27.00mm OD x 1600.00mm | KOBProtective Plastic |
| 10. | YY32H01003D1 | [1] | HOSE | KOB |
| 11. | YY32H01002D2 | [1] | HOSE | KOB |
| 12. | YY32H01002D1 | [1] | HOSE | KOB |
| 13. | ZG15F04300 | [2] | COUPLING | KOB |
| 13-3. | ZG15G04300 | [2] | GASKET,43mm ID x 58mm OD | KOB Superseded by part number: R44P0089D7S3 |
| 14. | LP21V00004F1 | [1] | VALVE | KOB |
| 15. | LP21V00010F1 | [1] | VALVE | KOB |
| 16. | 2444Z3502 | [1] | HYD CONNECTOR | KOB |
| 16-1. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 17. | 2444Z3715 | [1] | 90 ELBOW | KOB90° -- 1/2" PF x 56mm Long (Incls. O-Ring ZD12P01800) |
| 18. | 2444Z2360 | [1] | TEE | KOB(2) 1/2" PF x 3/8" PF x 64mm Long (Incls. O-Ring ZD12P01400) |
| 19. | 2444Z3945 | [1] | TEE | KOB1/2" PF x 74mm Long (Incls. O-Ring ZD12P01800) |
| 20. | ZX22M08120 | [1] | HOSE ASSY. | KOB |
| 21. | ZX32M08070 | [1] | HOSE ASSY. | KOB700mm Long (27-1/2 in) |
| 22. | ZX32M08185 | [1] | HOSE | KOB |
| 23. | ZW16H10000 | [4] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 24. | ZS18C10075 | [4] | SCREW,Hex, M10 x 75mm | KOBM10x1.50x75mm |
| 25. | ZD11G04500 | [1] | O-RING,44.40mm ID x 50.60mm OD x 3.10mm | KOBID 44.40 ± 0.41 x OD 50mm |
| 26. | 2420T2948D2 | [1] | U-BOLT | KOBM08x1.25x ID 38 x 72mm Long |
| 27. | ZW16H08000 | [4] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 28. | ZN18C08007 | [5] | NUT | KOBM08x1.25mm |
| 29. | YN20M01046DJ | [1] | PROTECTIVE SLEEVE,22.10mm ID x 27.00mm OD x 1000.00mm | KOBProtective Plastic |
| 30. | PY01P01043D3 | [5] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 31. | HH25R12008G2 | [1] | ELEC CONNECTOR | KOB |
| 31-1. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 32. | YX32H01010P1 | [2] | RUBBER | KOB |
| 33. | ZS18C08050 | [1] | SCREW,Hex, M8 x 50mm | KOBM08x1.25x50mm |
| 34. | YX32H01011P1 | [5] | BUSHING,33mm ID x 49mm OD x 50mm L | KOBID 33 x OD 43 x 50mm Long |
| 35. | YX32H01009D1 | [1] | SPACER | KOB |
| 36. | YX32H01012D1 | [1] | RUBBER | KOB |
| 37. | PY01P01043D6 | [1] | CABLE TIE,4.80mm W x 383mm L | KOBWire Ties -- 368mm Long |
