神钢零件查询(DOZER) - ATTACHMENT - SK115SR-1E, -1ES, SK135SR-1E, LC-1E, LC-1ES (1/02-12/03) (01-007[01]) - CONTROL LINES, REMOTE, P/N YV68H00005F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
316 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YV68H00005F2 | [1] | LINE | KOB |
| 1. | YT03M01069F3 | [1] | LEVER ASSY. | KOBDozer |
| 1-3. | ZR16X02000 | [1] | RING | KOBRetaining -- ID 18.5 x OD 20 x Th 1.2mm |
| 1-4. | ZW16X20000 | [1] | WASHER | KOBID 20 x OD 37 x Th 3.2mm |
| 1-5. | ZS18C08025 | [2] | SCREW,Hex, M8 x 25mm | KOB |
| 1-6. | ZN18C08007 | [2] | NUT | KOBM08x1.25mm |
| 1-8. | YT03M01152F1 | [1] | LEVER | KOB |
| 1-8A. | YT03M01151P1 | [1] | LEVER | KOB Superseded by part number: YT03M01152F1 |
| 1-8B. | 2405R312D2020 | [1] | BUSHING | KOB Superseded by part number: QP103701-2610 |
| 1-9. | YT03M01153P1 | [1] | BRACKET | KOB |
| 2. | PV03M01043P1 | [1] | HANDLE GRIP | KOB |
| 3. | YT03M01121D3 | [1] | BOWDEN CONTROL | KOB |
| 4. | YT03M01150P1 | [1] | ROD | KOB |
| 7. | YX03M01010P1 | [1] | STUD | KOB |
| 8. | 2420Z681 | [1] | ROD | KOB |
| 9. | ZN18C08007 | [1] | NUT | KOBM08x1.25mm |
| 10. | ZM22C08020 | [5] | BOLT | KOBM08x1.25x20mm (Incls. Washer & Lockwasher) |
| 11. | YT03M01114P1 | [1] | BOOT | KOB |
| 12. | PY01P01043D2 | [1] | CABLE TIE,4.60mm W x 202mm L | KOB Superseded by part number: YT50C01100P1 |
| 14. | YX03M01022P1 | [1] | SUPPORT | KOB |
| 15. | PY20T01011P2 | [1] | LABEL | KOB |
| 16. | ZW16X06000 | [1] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 17. | ZR36X00500 | [1] | SNAP RING | KOBE-Ring -- Shaft 05mm x OD 11mm Superseded by part number: 800-436 |
