神钢零件查询(DOZER) - ATTACHMENT - SK115SR-1E, -1ES, SK135SR-1E, LC-1E, LC-1ES (1/02-12/03) (02-004) - HYD LINES, LOW, P/N YV02H00005F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
358 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YV02H00005F1 | [1] | HYD LINES, LOW | |
| A1. | YV02H01049P1 | [1] | TUBE | KOB |
| A2. | YV02H01050P1 | [1] | TUBE | KOB |
| A3. | YV02H01051P1 | [1] | TUBE | KOB |
| A4. | YV02H01052P1 | [1] | TUBE | KOB |
| A5. | YV02H01053P1 | [1] | TUBE | KOB |
| A6. | YV02H01054P1 | [1] | TUBE | KOB |
| A7. | YV02H01055P1 | [1] | RIGID TUBE | KOBTUBE |
| A8. | YV02H01056P1 | [1] | RIGID TUBE | KOBTUBE |
| A9. | YV02H01057P1 | [1] | RIGID TUBE | KOBTUBE |
| A10. | YV02H01058P1 | [1] | RIGID TUBE | KOBTUBE |
| A11. | YV02H01059P1 | [1] | RIGID TUBE | KOBTUBE |
| A12. | YV02H01060P1 | [1] | RIGID TUBE | KOBTUBE |
| A13. | YV02H01061P1 | [1] | TUBE | KOB |
| A14. | YV02H01062P1 | [1] | TUBE | KOB |
| A15. | YX02H01017P1 | [1] | RIGID TUBE | KOB |
| A16. | YX02H01018P1 | [1] | RIGID TUBE | KOB |
| A17. | YX02H01019P1 | [1] | RIGID TUBE | KOB |
| A18. | YX02H01020P1 | [1] | TUBE | KOB |
| A19. | ZX23M04170 | [2] | FLEXIBLE HOSE | KOBHOSE |
| A20. | ZX56N08086 | [4] | HOSE | KOB860mm Long (33-49/64 in) |
| A21. | LP02H01075P1 | [2] | CLAMP | KOB |
| A22. | ZA23B22000 | [4] | HYD CONNECTOR | KOBM30x1.50x38mm Long |
| A23. | ZA23B18000 | [2] | HYD CONNECTOR | KOB |
| A24. | ZA53B15000 | [2] | TEE | KOB |
| A25. | 2432T1773 | [4] | CLAMP | KOB |
| A26. | LP02H01074P1 | [2] | CLAMP | KOB |
| A27. | YW02H01074P1 | [4] | SPACER | KOB |
| A28. | ZW16X08000 | [4] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| A29. | ZW26X08000 | [6] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| A30. | ZS18C08040 | [4] | SCREW,Hex, M8 x 40mm | KOBM08x1.25x40mm |
| A31. | ZS18C08080 | [2] | SCREW,Hex, M8 x 80mm | KOBM08x1.25x80mm |
| A32. | ZN18C08007 | [2] | NUT | KOBM08x1.25mm |
| A33. | 2420Z1224D4 | [4] | HOSE | KOBGuard -- ID 22 x OD 26 x 300mm Long (11-13/16 in) |
| A34. | PY01P01043D3 | [10] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| . . | YX19H00003F1 | [1] | LINE | KOB |
| B1. | 2444Z2320 | [4] | ELEC CONNECTOR | KOB1"PF-M30x1.50x48mm Long |
| B2. | ZH22X04000 | [2] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| B2-1. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| B3. | 2444Z2887 | [1] | TEE | KOB |
| B4. | ZD12P02900 | [4] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| B5. | ZD12P01800 | [3] | O-RING | KOBID 17.8mm x OD 20.2mm |
| B6. | ZA23F15008 | [2] | HYD CONNECTOR | KOB |
| . . | YX13H00001F1 | [1] | LINE | KOB |
| C1. | ZA23H15008 | [4] | HYD CONNECTOR | KOB |
| C2. | ZD12P01800 | [4] | O-RING | KOBID 17.8mm x OD 20.2mm |
