神钢零件查询(DOZER) - ATTACHMENT - SK200SR, SK200SR-1S, & SK200SRLC-1S (1/91-12/03) (02-003) - JOINT INSTAL, SWIVEL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
689 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YX19H00004F1 | [1] | JOINT | KOB |
| A1. | YX55V00001F2 | [1] | FLEXIBLE JOINT | KOBJOINT ASSY, SWIVEL Superseded by part number: YX55V00001F3 |
| A2. | ZS18C12025 | [3] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
| A3. | ZS18F20120 | [1] | SCREW | KOBM20x1.50x120mm |
| A4. | ZW16X12000 | [3] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| A5. | ZN18F20016 | [1] | NUT | KOBM20x1.50mm |
| . . | YN19H00019F1 | [1] | HYDRO LINES, SWIVEL | |
| B1. | ZA23F28016 | [4] | CONNECTION | KOB1" PF - M36x1.50x49mm Long |
| B2. | ZA23F22008 | [2] | HYD CONNECTOR | KOB1/2" PT - M30x1.50 x 43mm Long |
| 33. | ZH22X04000 | [2] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| B4. | 2444Z2887 | [1] | TEE | KOB |
| B5. | ZD12P02900 | [4] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| B6. | ZD12P01800 | [3] | O-RING | KOBID 17.8mm x OD 20.2mm |
