神钢零件查询(DOZER) - ATTACHMENT - SK200SR, SK200SR-1S, & SK200SRLC-1S (1/91-12/03) (02-004) - HYD LINES, LOW Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
282 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB02H00003F1 | [1] | HYD LINES, LOW | |
| 1. | YN02H01420P1 | [1] | TUBE | KOBTUBE |
| 2. | YN02H01421P1 | [1] | TUBE | KOBTUBE |
| 3. | YN02H01422P1 | [1] | TUBE | KOBTUBE |
| 4. | YN02H01423P1 | [1] | TUBE | KOBTUBE |
| 5. | YN02H01424P1 | [1] | TUBE | KOBTUBE |
| 6. | YN02H01425P1 | [1] | TUBE | KOBTUBE |
| 7. | ZX23M04240 | [2] | FLEXIBLE HOSE | KOBHOSE |
| 8. | 2420Z1224D4 | [4] | HOSE | KOBGuard -- ID 22 x OD 26 x 300mm Long (11-13/16 in) |
| 9. | PY01P01043D3 | [10] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 10. | YN02H01187P1 | [2] | CLAMP | KOB |
| 11. | YN02H01188P1 | [2] | CLAMP | KOB |
| 12. | 2418T24324D2 | [4] | SPACER | KOB |
| 13. | ZS18C08040 | [4] | SCREW,Hex, M8 x 40mm | KOBM08x1.25x40mm |
| 14. | ZW16X08000 | [4] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 15. | ZW26X08000 | [4] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 16. | YB02H01023P1 | [1] | TUBE | KOBTUBE |
| 17. | YB02H01024P1 | [1] | TUBE | KOBTUBE |
| 18. | YB02H01025P1 | [1] | TUBE | KOBTUBE |
| 19. | YB02H01026P1 | [1] | TUBE | KOBTUBE |
| 20. | YB02H01027P1 | [1] | TUBE | KOBTUBE |
| 21. | YB02H01028P1 | [1] | TUBE | KOBTUBE |
| 22. | ZX56N10110 | [4] | HOSE | KOBHOSE |
| 23. | ZA53B22000 | [2] | TEE | KOB |
| 24. | ZC26X22011 | [4] | CLAMP | KOBSingle Line -- 38x29x65mm Long |
| 25. | ZS18C10090 | [2] | SCREW,Hex, M10 x 90mm | KOBM10x1.50x90mm |
| 26. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 27. | ZN18C10008 | [2] | NUT | KOBM10x1.50mm |
