| . . | YT68H00033F1 | [1] | CONTROL LINES, REMOTE | |
| A1. | PA30V00002F3 | [1] | PILOT VALVE | KOB Superseded by part number: PX30V00043F2 |
| A2. | HH25X04004G2 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| A3. | 2444Z2337 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| A4. | 2444T2524 | [1] | HYD CONNECTOR | KOB1/4" PF x 50mm Long (Incls. O-Ring ZD12P01100) |
| A5. | ZH22X04000 | [5] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| A6. | HH25R04004G4 | [1] | CONNECTION | KOB |
| A7. | 2444T2544 | [3] | ELBOW | KOB90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| A8. | ZH32X04000 | [3] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| A9. | 2420R349D064 | [1] | FLEXIBLE HOSE | KOB Superseded by part number: HX21E04065DX |
| A10. | 2420R349D230 | [1] | HOSE ASSY. | KOB2300mm Long (90-1/2 in) |
| A11. | 2420R349D225 | [1] | HOSE | KOB Superseded by part number: HX21E04225DX |
| A12. | 2420R349D255 | [1] | HOSE | KOB2550mm Long (100-25/64 in) Superseded by part number: HX21E04255DX |
| A13. | 2420R349D250 | [1] | HOSE,2500.00 mm | KOB |
| A14. | 2444R1119D105 | [1] | HOSE | KOB1050mm Long (41-21/64 in) |
| A15. | ZS28C06020 | [4] | SCREW,Hex Socket Head, M6 x 20mm | KOBM06x1.0x20mm |
| A16. | ZW16X06000 | [4] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| A17. | HH55Q04004G1 | [3] | TEE,1/4" ORB x 1/4" JIC x 1/4" JIC | KOB1/4" PF (Incls. O-Ring ZD12P01100) |
| A18. | 2444Z3322D2 | [1] | CONNECTION | KOB1/4"PF x 1/8"PT x 27mm Long (Incls. O-Ring ZD12P01100) |
| A19. | YT50S00013P1 | [1] | PRESSURE SWITCH | KOBand protection cap |
| A20. | YT50S00011P1 | [1] | PRESSURE SWITCH | KOBSWITCH, PRESSURE |
| A20-2. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| A21. | YT50S00012P1 | [1] | PRESSURE SWITCH | KOBSWITCH, PRESSURE |
| A21-2. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| . . | YT64H00041F1 | [1] | CONTROL LINES, VALVE | |
| B1. | YN35V00010F2 | [1] | VALVE | KOB |
| B2. | YT64H01054P1 | [1] | BRACKET | KOB |
| B3. | ZH32X04000 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| B4. | HH35X04004G3 | [1] | 90 ELBOW | KOB90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| B5. | 2420R349D120 | [1] | HOSE,6.35mm ID x 1200mm L | KOB |
| B6. | 2420R349D042 | [1] | HOSE ASSY. | KOBPF 1/4, 420mm Long (16-1/2 in) Superseded by part number: 2420R349D045 |
| B7. | 2444R1120D115 | [1] | HOSE | KOB |
| B8. | ZS18C06016 | [2] | SCREW,Hex, M6 x 16mm | KOBM06x1.0x16mm |
| B9. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| B10. | ZW16H06000 | [2] | WASHER | KOBID 06 x OD 15 x Th 3.2mm |
| B11. | ZW16H10000 | [2] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| . . | YT64H00040F1 | [1] | CONTROL LINES, BLOCK | |
| C1. | 2416N6141 | [1] | BLOCK | KOB |
| C2. | ZH22X06000 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| C3. | ZH32X06000 | [4] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| C4. | ZH32X04000 | [3] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| C5. | ZS18C08040 | [2] | SCREW,Hex, M8 x 40mm | KOBM08x1.25x40mm |
| C6. | ZW16H08000 | [2] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| C7. | HH55Q06006G1 | [1] | TEE | KOB3/8" PF (Incls. O-Ring ZD12P01400) |
| C8. | ZH22X04000 | [2] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| C9. | HH55Q04004G1 | [1] | TEE,1/4" ORB x 1/4" JIC x 1/4" JIC | KOB1/4" PF (Incls. O-Ring ZD12P01100) |
| C10. | ZH42X06000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOB45° -- (Incls. O-Ring 237-6006) |
| C11. | ZH32X04006 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400) |
| C12. | 2444Z2525 | [1] | HYD CONNECTOR | KOB1/4"PFx35mm Long (Incls. O-Ring ZD12P01100) Superseded by part number: 72217408 |
| C13. | 2444Z2894 | [1] | 90 ELBOW | KOBElbow, 90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| C14. | 2444Z3155 | [1] | 90 ELBOW,PF 3/8" Fem x PF 3/8" Male | KOB90° -- (PF 3/8) (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 Superseded by part number: YT42H01128P1 |
