神钢零件查询(DOZER) - ATTACHMENT - SK70SR-1E EXCAVATORS ASN YT02-04001 (1/04-12/04) (01-014) - SEAT GROUP (PTPA DOZER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
572 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT25M00021F3 | [1] | SEAT GROUP | |
| 1. | YT25M01054P1 | [1] | SEAT | KOB |
| 2. | YT25M01002P2 | [2] | SUPPORT | KOB |
| 3. | YT25M01027F1 | [1] | RAIL ASSY. | KOB |
| 4. | YT25M01053P1 | [1] | SUPPORT | KOB |
| 6. | YN25M01035P1 | [1] | PLATE | KOB |
| 7. | ZS28C08020 | [4] | SCREW,Hex Socket Head, M8 x 20mm | KOBM08x1.25x20mm |
| 8. | YT25M01052P1 | [1] | COVER | KOB |
| 9. | ZS28C10025 | [4] | SCREW,Hex Socket Head, M10 x 25mm | KOBM10x1.50x25mm |
| 10. | ZW16X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 11. | ZW26K08000 | [8] | LOCK WASHER | KOBID 08 x OD 13 x Th 2.0mm |
| 12. | ZW26K10000 | [4] | LOCK WASHER | KOBLock -- ID 10 x OD 15.7 x Th 2.5mm Superseded by part number: 12581679 |
| 13. | ZM22C08025 | [6] | BOLT | KOBM08x1.25x25mm (Incls. Washer & Lockwasher) |
| 14. | ZW16X08000 | [4] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 15. | ZS28C08016 | [8] | SCREW,Hex Socket Head, M8 x 16mm | KOBM08x1.25x16mm |
| 16. | ZM22C08020 | [4] | BOLT | KOBM08x1.25x20mm (Incls. Washer & Lockwasher) |
| 17. | ZM66C06016 | [4] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| 18. | ZM12C08030 | [4] | BOLT | KOBM08x1.25x30mm (Incls. Lockwasher) |
| 19. | ZW16H08000 | [4] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 20. | YT03M01076F2 | [1] | SUPPORT | KOBASSY |
| 20-2. | YT03M01066P1 | [1] | ROLLER,12.7mm OD x 19mm L | KOB |
| 20-3. | YT03M01065P1 | [1] | PIN | KOBOD 8.5 x 34.9mm Long |
| 20-4. | ZR36X00700 | [1] | RING | KOBE-Ring -- Shaft 07mm x OD 14mm |
| 20-5. | YT03M01083P2 | [1] | SUPPORT | KOB |
| 20-6. | ZW16X08000 | [1] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 23. | YT25M01055P1 | [1] | BRACKET | KOB |
