| . . | YT02H000016F1 | [1] | HYD LINES, LOW | |
| A1. | LF02H01001P1 | [1] | TUBE | KOB |
| A2. | LF02H01002P1 | [1] | TUBE | KOB |
| A3. | LF02H01003P1 | [1] | TUBE | KOB |
| A4. | LF02H01004P1 | [1] | TUBE | KOB |
| A5. | LF02H01005P1 | [1] | TUBE | KOB |
| A6. | LF02H01006P1 | [1] | TUBE | KOB |
| A7. | LF02H01007P1 | [1] | TUBE | KOB |
| A8. | LF02H01008P1 | [1] | TUBE | KOB |
| A9. | YT02H01096P1 | [1] | TUBE | KOB |
| A10. | 2418T16830 | [1] | TUBE | KOB |
| A11. | ZX55M06090 | [1] | HOSE | KOB |
| A12. | ZX55M06088 | [1] | HOSE | KOB |
| A13. | ZX65M06160 | [2] | HOSE | KOB |
| A14. | ZX55M06150 | [1] | HOSE | KOB |
| A15. | ZX55M06135 | [1] | HOSE | KOB |
| A16. | ZX55M06050 | [1] | HOSE | KOB |
| A17. | ZX23M06050 | [1] | FLEXIBLE HOSE | KOB |
| A18. | ZX54M04058 | [1] | HOSE | |
| A19. | ZA53B15000 | [1] | TEE | KOB |
| A20. | ZA53B10000 | [1] | TEE | KOB(3) M16x1.50x46mm Long (No O-Ring supplied) |
| A21. | 2432P2657 | [2] | CLAMP | KOB |
| A22. | 2432T5305 | [2] | CLAMP | KOB |
| A23. | ZS18C08040 | [6] | SCREW,Hex, M8 x 40mm | KOBM08x1.25x40mm |
| A24. | ZW26X08000 | [6] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| A25. | ZW16X08000 | [4] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| A26. | 2418T24324D1 | [2] | SPACER | KOB |
| A27. | LE02H01031P1 | [2] | SPACER | KOB |
| A28. | PY01P01043D3 | [15] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| A29. | YT02H01103P1 | [1] | TUBE | KOB |
| A30. | YT02H01104P1 | [1] | TUBE | KOB |
| A31. | YT02H01105P1 | [1] | TUBE | KOB |
| A32. | YT02H01106P1 | [1] | TUBE | KOB |
| A33. | ZX55M06058 | [1] | FLEXIBLE HOSE | KOB Superseded by part number: ZX55M06060 |
| A34. | ZC36X15009 | [2] | CLAMP | KOB |
| . . | YT19H00007F1 | [1] | HYD LINES, SWIVEL | |
| B1. | ZA23F18008 | [4] | HYD CONNECTOR | KOB1/2" PF - M26x1.50x41mm Long (No O-Ring supplied) |
| B2. | ZA23F15006 | [1] | HYD CONNECTOR | KOB3/8"PF - M22x1.50 x 37mm Long (No O-Ring supplied) |
| B3. | ZA23F10004 | [1] | HYD CONNECTOR | KOB1/4" PF x M16x1.50 x 33mm Long |
| B4. | ZH22X04000 | [1] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| B4-1. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| B5. | 2444T3402 | [1] | TEE | KOBTee -- (Incls. O-Ring 237-6004) Superseded by part number: HH55V06006G3 |
| B5-1. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| B6. | ZH32X06000 | [4] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| B6-1. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| B7. | ZE72X04000 | [1] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| B7-1. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| B8. | ZD12P01800 | [4] | O-RING | KOBID 17.8mm x OD 20.2mm |
| B9. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| B10. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| . . | YT02H01021F1 | [1] | HYD LINES, SELECTOR VALVE | |
| C1. | ZH22X04000 | [1] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| C1-1. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| C2. | ZH32X06000 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| C2-1. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| C3. | 2444T3290 | [1] | ELBOW | KOB Superseded by part number: 2444Z2338 |
| C3-1. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| C4. | ZA33F15006 | [3] | ELBOW | KOB |
| C5. | ZA23F15006 | [1] | HYD CONNECTOR | KOB3/8"PF - M22x1.50 x 37mm Long (No O-Ring supplied) |
| C6. | ZD12P01400 | [4] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| . . | YT13H00002F1 | [1] | HYD LINES, CYLINDER (TILT) | |
| D1. | ZH32X06000 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| . . | YT13H00003F1 | [1] | HYD LINES, CYLINDER (ANGLE) | |
| E1. | ZH32X06000 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| E2. | 2444Z2891 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
