神钢零件查询(DOZER) - ATTACHMENT - SK70SR-1E EXCAVATORS ASN YT02-04001 (1/04-12/04) (02-009) - DOZER ASSY (ANGLE DOZER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
833 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 0. | YR01V00015F1 | [1] | HYDRAULIC CYLINDER | KOB, Start Serial: YT01~ |
| 0. | YT01V00020F1 | [1] | CYLINDER ASSY. | KOB, Start Serial: YT02~ |
| . . | YT51B00012F1 | [1] | DOZER GROUP | |
| A1. | YT51B01006P1 | [1] | COVER | KOB |
| A2. | ZS18C10016 | [4] | SCREW,Hex, M10 x 16mm | KOBM10x1.50x16mm |
| A3. | ZW16X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| A4. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| A5. | ZG91V02000 | [5] | LUBE NIPPLE,67 Degree x 1/8" PT | KOB67° x 1/8" PT Superseded by part number: 72283072 |
| . . | YT51B00011F1 | [1] | DOZER ASSY (WITHOUT EXTENSION) | DOZER ASSY (WITHOUT EXTENSION) |
| . . | YT51B00011F2 | [1] | DOZER ASSY (WITH EXTENSION) | DOZER ASSY (WITH EXTENSION) |
| B1. | YT51B01012F1 | [1] | FRAME ASSY | |
| B1-1. | YT51B01008P1 | [1] | FRAME | |
| B1-2. | YT51B01002P1 | [2] | BUSHING | KOB |
| B2. | YT51B00010P1 | [1] | DOZER BLADE | KOB |
| B3. | 2406N759 | [1] | LINK | KOB |
| B4. | 2419T3570 | [3] | PIN | KOB |
| B5. | ZS18C10100 | [3] | SCREW,Hex, M10 x 100mm | KOBM10x1.50x100mm |
| B6. | ZN18C10008 | [6] | NUT | KOBM10x1.50mm |
| B7. | 2412P398 | [1] | EXTENSION | KOB |
| B8. | ZS18C12035 | [5] | SCREW,Hex, M12 x 35mm | KOBM12x1.75x35mm |
| B9. | ZW26X12000 | [5] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| B10. | ZN18C12010 | [5] | NUT | KOBM12x1.75mm |
| . . | YT51B00002F1 | [1] | DOZER INSTAL | |
| C1. | YT51B01003P1 | [2] | PIN | KOB |
| C2. | HS18C12100G1 | [2] | SCREW | KOB Superseded by part number: HS18C12100G2 |
| C3. | ZN18C12010 | [4] | NUT | KOBM12x1.75mm |
| C4. | 2445R138D1 | [4] | SEAL,50mm ID x 65mm OD x 4mm Thk | KOB |
| C5. | B16T0442D25 | [2] | SHIM,80mm OD x 52mm ID x 1.2mm Thk | KOB |
| C6. | B16T0442D23 | [2] | SHIM,80mm OD x 52mm ID x 1.6mm Thk | KOB |
| C7. | B16T0442D24 | [2] | SHIM,80mm OD x 52mm ID x 2.3mm Thk | KOB |
| . . | YT51B00004F1 | [1] | CYLINDER INSTAL | |
| D1. | YT51B01004P1 | [2] | PIN | KOB |
| D2. | HS18C12125G1 | [2] | SCREW | KOB |
| D3. | ZN18C12010 | [4] | NUT | KOBM12x1.75mm |
| D4. | B16T0442D1 | [2] | SHIM,130mm OD x 72mm ID x 1.2mm Thk | KOB |
| D5. | B16T0442D2 | [2] | SHIM,130mm OD x 72mm ID x 1.6mm Thk | KOB |
| D6. | B16T0442D5 | [2] | SHIM,130mm OD x 72mm ID x 2.3mm Thk | KOB |
