神钢零件查询(DOZER) - ATTACHMENT - SK70SR-1E EXCAVATORS ASN YT02-04001 (1/04-12/04) (02-010) - DOZER ASSY (PTPA DOZER), P/N YT01V00020F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
702 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 0. | YT01V00020F1 | [1] | CYLINDER ASSY. | KOB |
| . . | YT51B00022F1 | [1] | DOZER GROUP | |
| A1. | YT51B01006P1 | [1] | COVER | KOB |
| A2. | ZS18C10016 | [4] | SCREW,Hex, M10 x 16mm | KOBM10x1.50x16mm |
| A3. | ZW16X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| A4. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| A5. | ZG91S02000 | [7] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| A6. | ZG91V02000 | [3] | LUBE NIPPLE,67 Degree x 1/8" PT | KOB67° x 1/8" PT Superseded by part number: 72283072 |
| A7. | YT51B01044P1 | [1] | COVER | KOBCOVER |
| A8. | 2420T6786 | [4] | BOLT,M12 x 1.75 x 25mm | KOBM12x1.75x25mm (Incls. Washer & Lockwasher) Superseded by part number: ZM32C12025 |
| . . | YT51B00017F1 | [1] | DOZER ASSY | |
| B1. | YT51B00018F1 | [1] | DOZER ASSY | |
| B2. | YT51B01025F1 | [1] | FRAME ASSY | |
| B2-1. | NSS | [1] | NOT SOLD SEPARAT | CONFRAME |
| B2-2. | 2405T1694 | [2] | BUSHING | KOB |
| B2-3. | YT51B01002P1 | [2] | BUSHING | KOB |
| B3. | YT51B01030P1 | [1] | PIN | KOBPIN |
| B4. | ZW13H42000 | [1] | WASHER | KOB |
| B5. | ZN22C42046 | [1] | NUT | KOBNUT |
| B6. | ZP15D08071 | [1] | COTTER PIN | KOBPin, Cotter Superseded by part number: ZP15D08100 |
| . . | YT51B00002F1 | [1] | DOZER INSTAL | |
| C1. | YT51B01003P1 | [2] | PIN | KOB |
| C2. | HS18C12100G1 | [2] | SCREW | KOB Superseded by part number: HS18C12100G2 |
| C3. | ZN18C12010 | [4] | NUT | KOBM12x1.75mm |
| C4. | 2445R138D1 | [4] | SEAL,50mm ID x 65mm OD x 4mm Thk | KOBDust -- ID 50 x OD 65 x Th 4mm |
| C5. | B16T0442D25 | [2] | SHIM,80mm OD x 52mm ID x 1.2mm Thk | KOBID 52 x OD 80 x Th 1.2mm |
| C6. | B16T0442D23 | [2] | SHIM,80mm OD x 52mm ID x 1.6mm Thk | KOBID 52 x OD 80 x Th 1.6mm |
| C7. | B16T0442D24 | [2] | SHIM,80mm OD x 52mm ID x 2.3mm Thk | KOBID 52 x OD 80 x Th 2.3mm |
| . . | YT51B00004F1 | [1] | CYLINDER INSTAL | |
| D1. | YT51B01004P1 | [2] | PIN | KOB |
| D2. | HS18C12125G1 | [2] | SCREW | KOB |
| D3. | ZN18C12010 | [4] | NUT | KOBM12x1.75mm |
| D4. | B16T0442D1 | [2] | SHIM,130mm OD x 72mm ID x 1.2mm Thk | KOBID 72 x OD 130 x Th 1.2mm |
| D5. | B16T0442D2 | [2] | SHIM,130mm OD x 72mm ID x 1.6mm Thk | KOBID 72 x OD 130 x Th 1.6mm |
| D6. | B16T0442D5 | [2] | SHIM,130mm OD x 72mm ID x 2.3mm Thk | KOBID 72 x OD 130 x Th 2.3mm |
| . . | YT51B00021F2 | [1] | CYLINDER INSTAL (TILT) | |
| E2. | YT51B01039P1 | [1] | COVER | |
| E3. | YT51B01015P1 | [1] | PIN | KOBPIN |
| E4. | YT51B01014P1 | [1] | PIN | KOBPIN |
| E5. | ZS18C10080 | [2] | SCREW,Hex, M10 x 80mm | KOBM10x1.50x80mm |
| E6. | ZN18C10008 | [4] | NUT | KOBM10x1.50mm |
| E7. | YT01V00014F1 | [1] | CYLINDER ASSY. | KOB |
| . . | YT51B00023F1 | [1] | CYLINDER INSTAL (ANGLE) | |
| F1. | YT01V00008F1 | [1] | CYLINDER ASSY. | KOB |
| F2. | YT51B01040P1 | [1] | COVER | KOBCOVER |
| F3. | YT51B01016P1 | [1] | PIN | KOBPIN |
| F4. | YT51B01017P1 | [1] | PIN | KOBPIN |
| F5. | ZS18C10090 | [2] | SCREW,Hex, M10 x 90mm | KOBM10x1.50x90mm |
| F6. | ZN18C10008 | [4] | NUT | KOBM10x1.50mm |
