神钢零件查询(EXTRA) - AND BREAKER ATTACHMENT - K907 II ASN YN0101 & K907LC II ASN YQ0101 (1/88-12/06) (02-001) - REWORK, CONTROL ASSY (EXTRA) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
283 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J9395F1 | [1] | CONTROL ASSY REWORK | CONTROL ASSY REWORK |
| 1. | 2406P2616 | [1] | PEDAL | KOB |
| 2. | ZS23C10016 | [1] | SCREW,Hex Socket Head, M10 x 16mm | KOBM10x1.50x16mm Superseded by part number: ZS28C10016 |
| 3. | ZW22K10000 | [1] | LOCK WASHER | KOBLock -- ID 10.2 x OD 15.7 x Th 2.5mm |
| 4. | 2408P504F1 | [1] | HOOK ASSY | HOOK ASSY |
| 4-1. | 2406T2355D1 | [1] | BAR | |
| 4-2. | ZW16X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 4-3. | ZP16K02516 | [2] | COTTER PIN | KOB Superseded by part number: ZP16K02520 |
| 4-4. | 2417T514 | [1] | SPRING | SPRING |
| 4-5. | 2416P8715 | [1] | BRACKET | |
| 5. | 2436U1142F1 | [1] | PILOT VALVE | KOB |
| 6. | 2436U1314F1 | [1] | VALVE | KOBASSY, SOLENOID |
| 7. | ZS13C06020 | [2] | CAPSCREW M06x1.0x20mm | CAPSCREW M06x1.0x20mm |
| 8. | ZW22X06000 | [2] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 9. | ZH21M08004 | [1] | HYD CONNECTOR | KOB |
| 10. | ZH32X04000 | [7] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 11. | ZH31M08004 | [1] | ELBOW | KOB |
| 13. | 2444T2501D2 | [1] | TEE | KOB |
| 14. | 2444T2529 | [1] | TEE | KOB1/4" PF x 50mm Long (Incls. O-Ring ZD12P01100) |
| 15. | 2444T2501D1 | [1] | TEE | KOB |
| 16. | ZH51K08000 | [1] | TEE | KOB |
| 17. | ZS13C08025 | [2] | SCREW | KOBM08x1.25x25mm Superseded by part number: ZS18C08025, 77276313 |
| 18. | ZW22X08000 | [2] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 20. | 2420R349D186 | [1] | HOSE | KOB Superseded by part number: HX21E04186DX |
| 21. | 2420R349D210 | [1] | FLEXIBLE HOSE | KOB2100mm Long (82-11/16 in) |
| 22. | 2420R349D030 | [1] | HOSE,300.00 mm | KOB |
| 23. | 2420R349D090 | [1] | HOSE,6.35mm ID x 900mm L | KOB900mm Long (35-7/16 in) |
| 24. | ZX15K08030 | [1] | FLEXIBLE HOSE | KOB |
| 25. | ZX15K08065 | [1] | TUBE | KOB |
| 26. | ZX15K08011 | [1] | TUBE,N2 | TUBE,N2 |
| 27. | ZX15K08090 | [1] | FLEXIBLE HOSE | KOB |
| 28. | 2479Z849 | [1] | SWITCH | KOBTOGGLE Superseded by part number: 2479Z514 |
| 29. | 2479Z1441D2 | [1] | HARNESS | KOB |
| 30. | 2479Z976D4 | [1] | HARNESS | KOB |
| 31. | 2479Z977 | [1] | HARNESS | KOB |
| 32. | NSS | [1] | NOT SOLD SEPARAT | CONCONTROL ASSY |
| 34. | 2406R256F2 | [1] | HANDLE | KOBASSY |
| 35. | ZH52X04000 | [1] | TEE,30 Degree Fl, Male, PF 1/4" x 1/4" x 1/4", O-Ring | KOB1/4" PF (Incls. O-Ring 237-6004) |
| 36. | 2420R349D450 | [1] | FLEXIBLE HOSE | KOB4500mm Long (177-5/32 in) |
| 37. | 2412T953 | [1] | DECAL | KOB |
