| . . | 24100J9928F1 | [1] | CONTROL ASSY, REWORK | |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONCONTROL ASSY |
| 3. | 2406P2616 | [1] | PEDAL | KOB |
| 4. | ZS23C10016 | [1] | SCREW,Hex Socket Head, M10 x 16mm | KOBM10x1.50x16mm Superseded by part number: ZS28C10016 |
| 5. | ZW22K10000 | [1] | LOCK WASHER | KOBLock -- ID 10.2 x OD 15.7 x Th 2.5mm |
| 6. | 2436U1142F1 | [1] | PILOT VALVE | KOB |
| 7. | 2408P504F1 | [1] | HOOK ASSY | HOOK ASSY |
| 7-1. | 2406T2355D1 | [1] | BAR | |
| 7-2. | ZW16X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 7-3. | ZP16K02516 | [2] | COTTER PIN | KOB Superseded by part number: ZP16K02520 |
| 7-4. | 2417T514 | [1] | SPRING | SPRING |
| 7-5. | 2416P8715 | [1] | BRACKET | |
| 8. | ZS13C08025 | [2] | SCREW | KOBM08x1.25x25mm Superseded by part number: ZS18C08025, 77276313 |
| 9. | ZW22X08000 | [2] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 10. | 2436U1314F1 | [1] | VALVE | KOBASSY, SOLENOID |
| 11. | ZS13C06020 | [2] | CAPSCREW M06x1.0x20mm | CAPSCREW M06x1.0x20mm |
| 12. | ZW22X06000 | [2] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 13. | ZH31M08004 | [2] | ELBOW | KOB |
| 14. | 2444Z2525 | [1] | HYD CONNECTOR | KOB1/4"PFx35mm Long (Incls. O-Ring ZD12P01100) Superseded by part number: 72217408 |
| 15. | ZH32X04000 | [11] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 16. | ZH21M08004 | [1] | HYD CONNECTOR | KOB |
| 17. | 2444Z2516 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| 18. | ZH22X04000 | [3] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100), Serial Range: YQ0101-0379 |
| 19. | 2444Z2336 | [2] | TEE | KOBTee -- 1/4"x3/8"x3/8"PF (Incls. O-Ring ZD12P01100) |
| 20. | 2444T2501D2 | [1] | TEE | KOB |
| 21. | ZH51M08006 | [1] | TEE | KOB |
| 22. | 2444T2501D1 | [1] | TEE | KOB |
| 23. | 2444T2529 | [1] | TEE | KOB1/4" PF x 50mm Long (Incls. O-Ring ZD12P01100) |
| 24. | ZH51K08000 | [1] | TEE | KOB |
| 25. | 2420R349D090 | [1] | HOSE,6.35mm ID x 900mm L | KOB900mm Long (35-7/16 in) |
| 26. | 2420R349D030 | [1] | HOSE,300.00 mm | KOB |
| 27. | 2420R349D21 | [1] | HOSE | HOSE |
| 28. | 2420R349D070 | [1] | HOSE,700.00 mm | KOB700mm Long (27-9/16 in) |
| 29. | 2420R349D130 | [1] | FLEXIBLE HOSE | KOB1/4" PF, 1300mm Long (51-3/16 in) |
| 30. | 2420R349D240 | [1] | HOSE,2400.00 mm | KOB Superseded by part number: HX21E04240DX |
| 31. | 2420R349D250 | [1] | HOSE,2500.00 mm | KOB |
| 32. | 2420R349D110 | [1] | HOSE,1100.00 mm | KOB1100mm Long (43-19/64 in), Serial Range: YQ0101-YQ0379 Superseded by part number: HX21E04110DX |
| 33. | ZX15K08090 | [1] | FLEXIBLE HOSE | KOB |
| 34. | ZX15K08115 | [1] | TUBE, NYLON | |
| 35. | ZX15K08070 | [2] | FLEXIBLE HOSE | KOB |
| 36. | ZX15K08011 | [1] | TUBE,N2 | TUBE,N2 |
| 37. | ZX15K08030 | [1] | FLEXIBLE HOSE | KOB |
| 38. | 2479Z977 | [1] | HARNESS | KOB |
| 39. | 2479Z849 | [1] | SWITCH | KOBTOGGLE Superseded by part number: 2479Z514 |
| 40. | 2479Z976D4 | [1] | HARNESS | KOB |
| 41. | 2479Z1441D2 | [1] | HARNESS | KOB |
| 42. | 2420R349D035 | [1] | HOSE | KOB350mm Long (13-49/64 in) |
| 43. | ZH31M08006 | [2] | ELBOW | KOB |
| 44. | 2444Z2333 | [1] | TEE | KOB |
| 45. | 2406R256F2 | [1] | HANDLE | KOBASSY |
| 46. | ZH52X04000 | [1] | TEE,30 Degree Fl, Male, PF 1/4" x 1/4" x 1/4", O-Ring | KOB1/4" PF (Incls. O-Ring 237-6004), Start Serial: YQ0380 |
| 47. | 2420R349D260 | [1] | HOSE | KOB2600mm Long (102-23/64 in), Start Serial: YQ0380 Superseded by part number: HX21E04260DX |
| 48. | 2420R349D220 | [1] | HOSE,2200.00 mm | KOB, Start Serial: YQ0380 Superseded by part number: HX21E04220DX |
| 49. | 2420R349D150 | [1] | HOSE,6.35mm ID x 1500mm L | KOBPF 1/4, Start Serial: YQ0380 |
| 50. | 2412T953 | [1] | DECAL | KOB |
