纽荷兰零件查询(E235BSRNLC) - CRAWLER EXCAVATOR ASN YU05-02001 (08-006) - CONTROL LINES, REMOTE (EXTRA & NIBBLER & BREAKER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
258 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF68H00025F1 | [1] | CONTROL LINES,REMOTE | |
| A1. | YN30V00080F1 | [1] | VALVE | KOBASSY, PILOT |
| A2. | 2420R349D080 | [1] | HOSE,6.35mm ID x 800mm L | KOB |
| A3. | 2420R349D092 | [2] | HOSE | KOB Superseded by part number: 2420R349D095 |
| A4. | 2420R349D280 | [1] | HOSE | KOB Superseded by part number: HX21E04280DX |
| A5. | 2420R349D330 | [1] | HYDRAULIC HOSE,6.35 mm ID x 3300.00 mm | KOB Superseded by part number: HX21E04330DX |
| A6. | 2420R349D390 | [1] | HOSE,3900.00 mm | KOB |
| A7. | HH25X04004G2 | [1] | HYD CONNECTOR | KOB(WITH FILTER) |
| A8. | ZH22X04000 | [2] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB |
| A9. | ZH32X04000 | [5] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOB |
| A10. | ZH32X04006 | [2] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 3/8", O-Ring | KOB |
| A11. | ZH42X04000 | [1] | 45 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOB |
| A13. | ZE72X04000 | [1] | PLUG | KOB |
| A14. | 2444Z2525 | [1] | HYD CONNECTOR | KOB |
| A16. | LC52S00019P1 | [1] | SENSOR | SMPressure (Low Pressure) -- Replaced YX52S00013P1 (Incls. O-Ring ZD12P01100) |
| A16-2. | ZD12P01100 | [1] | O-RING | KOB(Part of LC52S00019P1), ID 10.80 ± 0.18 x OD 15mm |
| A17. | HM83C10030G1 | [4] | BOLT | KOBSEMS |
| A18. | YR30V00020F1 | [1] | VALVE | KOBASSY, PILOT |
| A19. | HH45X04004G5 | [1] | ELBOW | KOBELBOW (WITH FILTER) |
| A20. | 2420R349D082 | [1] | HYDRAULIC HOSE,6.35 mm ID x 820.00 mm | KOB Superseded by part number: 2420R349D085 |
| A21. | 2420R349D320 | [1] | HOSE ASSY. | KOB |
| . . | YF64H00057F1 | [1] | CONTROL LINES, BLOCK | |
| B1. | YN64H01338P1 | [1] | BLOCK | SM |
| B2. | ZM73C08020 | [3] | BOLT,M8x20mm - Course Thread | KOBM08x1.25x20mm (Incls. Washer) |
