纽荷兰零件查询(E235BSRNLC) - CRAWLER EXCAVATOR ASN YU05-02001 (07-002[01]) - NAME PLATE INSTAL (CAB) P/N YB22T00065F1 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
642 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB22T00065F1 | [1] | DATA PLAQUE | KOBNAME PLATE INSTAL [REQUIRED (WARN ING)] |
| 1. | PV20T01005P1 | [1] | LABEL | KOB |
| 2. | YN20T01350P1 | [1] | LABEL | KOB |
| 3. | PH20T01018P1 | [2] | WARNING DECAL | KOB |
| 4. | YB20T01095P1 | [1] | LABEL | KOB |
| 5. | PW22T01048P1 | [1] | IDENTITY PLATE | KOB |
| 6. | YN20T01862P1 | [1] | LABEL | KOBITCS |
| 7. | ZL11M03708 | [1] | LABEL | KOB |
| 9. | ZL11M06008 | [1] | LABEL | KOB |
| 10. | YN20T01799P1 | [1] | LABEL | KOB |
| 11. | YN20T01800P1 | [1] | LABEL | KOB |
| 12. | YN20T01353P1 | [1] | LABEL | KOB |
| 13. | YN20T01351P1 | [1] | LABEL | KOB |
| 17. | YN20T01685P1 | [1] | LABEL | KOB |
