| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB22T00063F1 | [1] | DATA PLAQUE | KOBNAME PLATE INSTAL [REQUIRED (EXTERIOR LABEL)] |
| 1. | YB20T01130P1 | [3] | SHEET | KOB |
| 2. | YN20T01282P1 | [6] | SHEET | KOB |
| 4. | YF20T01180P1 | [1] | LABEL | KOBLABEL Superseded by part number: YF20T01180P2 |
| 5. | YN20T02025P1 | [1] | LABEL | KOB |
| 6. | YF20T01181P1 | [1] | LABEL | KOB |
| 7. | PW22T00219P1 | [1] | DECAL | KOBDecal, New Holland Logo |
| . . | YB22T00063F2 | [1] | DATA PLAQUE | KOBNAME PLATE INSTAL [SELECT(LUBRICATION CHART/STD)] |
| 3. | YB20T01135P2 | [1] | LABEL | KOBLUBRICATION CHART |
| . . | YB22T00063F3 | [1] | DATA PLAQUE | KOBNAME PLATE INSTAL [SELECT(NHK LOGO)] |
| 8. | PH22T00098P1 | [1] | DATA PLAQUE | KOBNAME PLATE, NEW HOLLAND, KOBELCO |
| 9. | YY22T00108P1 | [1] | DECAL KIT | KOBNAME PLATE NEW HOLLAND, KOBELCO |
| . . | YB22T00063F4 | [1] | DATA PLAQUE | KOBNAME PLATE INSTAL [SELECT(MACIHNE NAME E235BSR/STD)] |
| 10. | YF22T00049P1 | [1] | DECAL | KOBNAME PLATE |
| 11. | YF22T00050P1 | [1] | DECAL | KOBNAME PLATE |
| 12. | YN22T00376P1 | [1] | DECAL | KOBNAME PLATE, ST VERSION-J |
| . . | YB22T00063F5 | [1] | DATA PLAQUE | KOBNAME PLATE INSTAL [SELECT(MACIHNE NAME E235BSR/LONG CRAWLER)] |
| 13. | YN22T00377P1 | [1] | DECAL | KOBNAME PLATE, LC VERSION-J |
| . . | YB22T00063F6 | [1] | DATA PLAQUE | KOBNAME PLATE INSTAL [SELECT(MACIHNE NAME E235BSR/NARR0W LONG CRAWLER)] |
| 14. | YF22T00051P1 | [1] | DECAL | KOBNAME PLATE, NLC VERSION-J |
