纽荷兰零件查询(E235BSRNLC) - CRAWLER EXCAVATOR ASN YU05-02001 (07-004[01]) - NAME PLATE INSTAL (CAB) P/N YB22T00066F1 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
955 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB22T00066F1 | [1] | DATA PLAQUE | KOBNAME PLATE INSTAL (NARROW LONG CRAWLER) |
| 1. | YF20T01174P2 | [1] | LABEL | KOBLABEL (600m/m SHOE) |
| 2. | YF20T01175P2 | [1] | LABEL | KOBLABEL (600m/m SHOE) |
| 10. | YF20T01203P1 | [1] | LABEL (600m/m SHOE), Start Serial: YU05-02099 | |
| 11. | YF20T01204P1 | [1] | LABEL (600m/m SHOE), Start Serial: YU05-02099 | |
| 12. | YF20T01205P1 | [1] | LABEL (700m/m SHOE), Start Serial: YU05-02099 | |
| 13. | YF20T01206P1 | [1] | LABEL (700m/m SHOE), Start Serial: YU05-02099 | |
| . . | YB22T00066F2 | [1] | DATA PLAQUE | KOBNAME PLATE INSTAL [REQUIRED(NOISE LEVEL)] |
| 3. | YF20T01198P1 | [1] | LABEL | KOBLABEL |
| . . | YB22T00066F3 | [1] | NAME PLATE INSTAL (STD) | |
| 4. | YF20T01184P1 | [1] | LABEL (600m/m SHOE) | |
| 5. | YF20T01185P1 | [1] | LABEL (600m/m SHOE) | |
| . . | YB22T00066F4 | [1] | NAME PLATE INSTAL (LONG CRAWLER) | |
| 6. | YF20T01186P1 | [1] | LABEL (600m/m SHOE) | |
| 7. | YF20T01187P1 | [1] | LABEL (600m/m SHOE) | |
| 8. | YF20T01189P1 | [1] | LABEL (700m/m SHOE) | |
| 9. | YF20T01190P1 | [1] | LABEL (700m/m SHOE) | |
