| . . | YB30H00002F2 | [1] | HYD LINES, PUMP | |
| 2. | YB30H01002P1 | [1] | RIGID TUBE | KOB |
| 3. | YB30H01003P1 | [2] | HOSE | KOB |
| 4. | YX30H01014D3 | [1] | HOSE | KOB |
| 5. | YX30H01014D2 | [1] | FLEXIBLE HOSE | KOB |
| 6. | ZD11G07500 | [1] | O-RING,74.40mm ID x 80.60mm OD x 3.10mm | KOBID 74.40 ± 0.65 x OD 80mm |
| 7. | ZD12P02600 | [2] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 8. | ZE13X12000 | [4] | CLAMP | KOBHalf -- (Incls. Capscrew & Lockwasher) |
| 9. | ZS18C10035 | [8] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 10. | ZS28C12030 | [4] | SCREW,Hex Socket Head, M12 x 30mm | KOBScrew -- M12x1.75x30mm |
| 11. | 2420T2948D11 | [2] | U-BOLT | KOBM08x1.25x ID 76 x 111mm Long |
| 12. | ZW16H08000 | [4] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 13. | ZW26X10000 | [12] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 14. | ZW26K12000 | [4] | LOCK WASHER | KOBID 12 x OD 17.8 x Th 2.5mm |
| 15. | ZN18C08007 | [8] | NUT | KOBM08x1.25mm |
| 16. | ZC16X08700 | [8] | CLIP | KOBClamp, Hose -- Min 77 x Max 96mm |
| 17. | LC52S00012P1 | [2] | SENSOR | KOBPressure (High Pressure) (replaced by LS52S00015P1) Superseded by part number: YY52S00033F1 |
| 17. | LS52S00015P1 | [2] | SENSOR | KOB(New part #) (Added by SB S030-41-K003) |
| 17-0. | YY52S00033F1 | [1] | PRESSURE SWITCH | KOBKit Includes Ref 17 - 17-3 (Refer to SB S030-41-K003) |
| 17-1. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 17-2. | LS30H01024P1 | [1] | HYD CONNECTOR | SM(Added with new part # press switch) |
| 17-3. | YT42H01128P1 | [1] | 90 ELBOW | KOB(Added with new part # press switch) |
| 18. | ZH32X08000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 1/2", O-Ring | KOBElbow, 90° -- 1/2"PT (Incls. O-Ring ZD12P01800) |
| 18-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 19. | YN03H01169P1 | [2] | GROMMET | KOB |
| 20. | PY01P01043D6 | [2] | CABLE TIE,4.80mm W x 383mm L | KOBWire Ties -- 368mm Long |
| 21. | YB30H01004P1 | [1] | TUBE | KOB |
| 22. | 2444Z2760 | [1] | HYD CONNECTOR | KOB1" PFx56.5mm Long (Incls. O-Ring ZD12P02900) |
| 22-1. | ZD12P02900 | [1] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 23. | 2444Z3203 | [1] | ELBOW | KOB Superseded by part number: HH35X16016G1 |
| 23-1. | ZD12P02900 | [1] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 24. | YX06H01003D5 | [1] | HOSE | KOB700mm Long (27-1/2 in) |
| 25. | YB30H01005P1 | [1] | FLANGE | KOBFLANGE |
| 26. | ZD12P03800 | [1] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| 27. | ZS18C10080 | [4] | SCREW,Hex, M10 x 80mm | KOBM10x1.50x80mm |
