纽荷兰零件查询(E235BSRNLC) - CRAWLER EXCAVATOR ASN YU05-02001 (05-011) - ARM GROUP, 2.94M (NIBBLER & BREAKER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
729 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN12B00880F1 | [1] | ARM GROUP, 2. 94M | |
| 1. | YN12B01939F1 | [1] | LINK | KOBLINK ASSY, BUCKET Superseded by part number: YN12B11101F1 |
| 1-1. | NSS | [1] | NOT SERVICED SEPARATELY | CONLINK, BUCKET |
| 1-2. | YN12B02221P1 | [4] | BUSHING,80mm ID x 95mm OD x 47mm L | KOB |
| 1-3. | LC12B01499P1 | [2] | BUSHING,80mm ID x 95mm OD x 89mm L | KOB |
| 2. | YN12B01321P1 | [1] | LINK | KOB Superseded by part number: YN12B11270P1 |
| 3. | YN12B01322P1 | [1] | LINK | KOB |
| 4. | YN12B02215P1 | [2] | PIN,80mm OD x 561mm L | KOB Superseded by part number: YN12B11170P1 |
| 5. | YN12B02216P1 | [1] | PIN | KOBPIN Superseded by part number: YN12B11271P1 |
| 6. | YN12B02217P1 | [1] | PIN,85mm OD x 478mm L | KOBPIN |
| 7. | HS18C16130G2 | [1] | BOLT,Hex, M16 x 130mm, Cl 10.9 | KOBCAP |
| 8. | HS18C16140G2 | [1] | SCREW,M16 x 140mm, Cl 10.9 | KOBCAP |
| 9. | ZN18C16013 | [4] | NUT | KOB |
| 10. | 2445R220D4 | [6] | SEAL,78.7mm ID x 95mm OD x 5mm Thk | KOBDUST |
| 11. | ZG91S02000 | [5] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOBGREASE |
| 12. | ZG91S04000 | [1] | LUBE NIPPLE | KOBGREASE |
| 13. | B16T0442D57 | [1] | SHIM,0.5mm Thk | KOB |
| 14. | B16T0442D44 | [1] | SHIM,0.9mm Thk | KOB |
| 15. | B16T0442D2 | [1] | SHIM,130mm OD x 72mm ID x 1.6mm Thk | KOB(1.6) |
| 16. | YN12B01122D1 | [2] | SHIM,82mm ID x 140mm OD x 0.5mm Thk | KOB(0.5) |
| 17. | YN12B01122D2 | [2] | SHIM,82mm ID x 140mm OD x 0.9mm Thk | KOB(0.9) |
| 18. | YN12B01122D3 | [2] | SHIM,82mm ID x 140mm OD x 1.6mm Thk | KOB(1.6) |
| 19. | YN12B01601D1 | [4] | SHIM,82mm ID x 140mm OD x 2mm Thk | KOB(2.0) |
| 20. | YN12B01602D1 | [2] | SHIM,72mm ID x 130mm OD x 2mm Thk | KOB(2.0) |
