纽荷兰零件查询(E235BSRNLC) - CRAWLER EXCAVATOR ASN YU05-02001 (05-012) - HYD LINES, ARM 2.94M (NIBBLER & BREAKER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
732 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN43H00203F1 | [1] | HYDRAULIC EQUIPMENT REEL | KOBHYD LINES, ARM 2. 94M |
| 1. | YN43H01641P1 | [1] | TUBE,42.7 mm OD x 1148.5, 88.6 mm Length | KOB |
| 2. | YN43H01642P1 | [1] | TUBE,34.0 mm OD x 1148.5, 88.6 mm Length | KOB |
| 3. | YN43H01211D7 | [1] | HOSE,25.4mm ID x 1700mm L | KOB |
| 4. | LC43H01011DF | [1] | HYDRAULIC HOSE,31.8mm ID x 1650mm L | KOB |
| 5. | 24100P3133F1 | [2] | VALVE | KOBASSY, STOP |
| 5-1. | 2436P317 | [1] | BODY, VALVE | |
| 5-2. | 2436T311 | [1] | VALVE | KOB |
| 5-3. | ZR16X04000 | [1] | RING | KOBSNAP |
| 5-4. | ZS23C06010 | [1] | SCREW,Hex Socket Head, M6 x 10mm | KOBCAP |
| 5-5. | ZD12G03500 | [1] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOB |
| 5-6. | ZD85G03500 | [1] | RING | KOBBACK UP |
| 5-7. | ZD12G04000 | [1] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOB |
| 5-8. | ZD75G04000 | [1] | BACK-UP RING | KOB |
| 5-9. | 2418T8945D1 | [1] | SPACER | KOB |
| 5-10. | ZD11G04000 | [2] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOB |
| 6. | YN43H01005P1 | [2] | HYD CONNECTOR | KOB |
| 7. | ZD12A02100 | [2] | O-RING | KOB |
| 8. | ZE13X16000 | [4] | FLANGE | KOBHALF |
| 9. | ZE13X20001 | [4] | CLAMP | KOBHALF Superseded by part number: ZE13X20000 |
| 10. | YN42H02361P1 | [4] | CLAMP,52mm ID, J Type | KOB |
| 11. | YN42H02363P1 | [4] | CLAMP,46mm ID, J Type | KOB |
| 12. | YN43H01524P1 | [2] | BUSHING,34mm ID x 53mm OD x 83mm L | KOB |
| 13. | YN42H02321P1 | [2] | BUSHING,42.7mm ID x 62mm OD x 83mm L | SM |
| 14. | ZD12P03400 | [2] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOB |
| 15. | ZD12P03800 | [2] | O-RING | KOB |
| 16. | ZM73C12030 | [8] | BOLT,M12x30mm - Course Thread | KOBSEMS |
| 17. | ZS18C08025 | [8] | SCREW,Hex, M8 x 25mm | KOBCAP |
| 18. | ZS28C14050 | [8] | CAPSCREW,Hex Socket Head, M14 x 50mm | KOBSCREW |
| 19. | YN43H01151P1 | [8] | WASHER | KOB |
| 21. | ZS28C12050 | [8] | CAPSCREW,Hex Socket Head, M12 x 50mm | KOBSCREW CAP |
| 22. | ZW26K12000 | [8] | LOCK WASHER | KOBLOCK |
| 23. | ZW26K14000 | [8] | LOCK WASHER | KOBLOCK |
