| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF60C00009F1 | [1] | COUNTERWEIGHT INSTAL | |
| . . | YF60C00007F1 | [1] | COUNTERWEIGHT INSTAL | |
| A1. | 2420T7781D5 | [4] | SCREW | KOBCAP |
| A2. | HY26Y37075G1 | [4] | WASHER | KOB |
| A3. | 2420T6013D4 | [2] | SHIM | KOB(2.3) |
| A4. | 2420T6013D5 | [2] | SHIM | KOB(3.2) |
| A5. | 2420Z1340D3 | [2] | PLUG | KOB |
| . . | YF60C00012F1 | [1] | COUNTERWEIGHT ASSY | |
| B1. | YB60C01027P1 | [1] | FOAM INSULATION | KOB |
| B2. | YB60C01028P1 | [1] | FOAM INSULATION | KOB |
| B3. | YB60C01029P1 | [1] | FOAM INSULATION | KOB |
| B4. | YB60C01030P1 | [1] | FOAM INSULATION | KOB |
| B5. | YB60C01031P1 | [1] | FOAM INSULATION | KOB |
| B6. | YB60C01032P1 | [1] | FOAM INSULATION | KOB |
| B7. | YB60C01033P1 | [1] | FOAM INSULATION | KOB |
| B8. | YB60C01034P1 | [1] | FOAM INSULATION | KOB |
| B9. | YB60C01026P1 | [1] | FOAM INSULATION | KOB |
| B10. | YF60C01049D1 | [1] | RUBBER BAND | KOB |
| B11. | YF60C01037P1 | [1] | FOAM INSULATION | KOB |
| B12. | YF60C01038P1 | [1] | FOAM INSULATION | KOB |
| B13. | YF60C01039P1 | [1] | FOAM INSULATION | KOBINSULATION Superseded by part number: YF60C01039P2 |
| B14. | YF60C01040P1 | [1] | FOAM INSULATION | KOB |
| B15. | YF60C01041P1 | [1] | FOAM INSULATION | KOB |
| B16. | YF60C01042P1 | [1] | FOAM INSULATION | KOB |
| B17. | YF60C01043P1 | [1] | FOAM INSULATION | KOB |
| B18. | YF60C01044P1 | [1] | FOAM INSULATION | KOB |
| B19. | YF60C01045P1 | [1] | FOAM INSULATION | KOB |
| B20. | YF60C01046P1 | [1] | FOAM INSULATION | KOB |
| B21. | YF60C01047P1 | [1] | RUBBER BAND | KOB |
| B22. | YF60C01050P1 | [1] | FOAM INSULATION | KOB |
| C1. | YF60C00011P1 | [1] | WEIGHT | KOBCOUNTERWEIGHT |
