纽荷兰零件查询(E235BSRNLC) - CRAWLER EXCAVATOR ASN YU05-02001 (01-012) - FUEL LINES New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
968 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF21P00002F1 | [1] | FUEL LINES | |
| 1. | YN21P01036F1 | [1] | FUEL FILTER | KOBASSY, SEE FIG. 01-013 Superseded by part number: YN21P01068F1 |
| 2. | YF21P01002P1 | [1] | BRACKET | KOBBRACKET |
| 7. | HX11F06260DY | [1] | HOSE,9.70mm ID x 2600mm L | KOB |
| 8. | HX11F06145DX | [1] | HOSE,9.70mm ID x 1450mm L | KOB |
| 9. | HX11F06160DX | [1] | HOSE,9.70mm ID x 1600mm L | KOB |
| 10. | YB21P01012P1 | [1] | HOSE | KOB |
| 11. | HX81X19250DX | [1] | TUBE | KOB2500mm Long (98-7/16 in) |
| 12. | HX81X19135DX | [1] | TUBE | KOBTUBE |
| 13. | HX81X19150DX | [1] | TUBE | KOB |
| 14. | HX81X19230DX | [1] | TUBE | KOBTUBE |
| 15. | HX11Y06042DX | [1] | HOSE | KOB |
| 16. | HX11Y06060DX | [1] | HOSE | KOB |
| 17. | PH05P01088D6 | [2] | CLIP | KOB |
| 18. | PH05P01088D7 | [6] | CLIP,13.6mm - 17.5mm | KOBClamp, Hose -- Min 13.6 x Max 17.5mm |
| 19. | PY01P01043D2 | [8] | CABLE TIE,4.60mm W x 202mm L | KOBWire Ties -- 160mm Long Superseded by part number: YT50C01100P1 |
| 20. | PY01P01043D3 | [2] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 21. | ZC48X24014 | [2] | CLIP | KOBClamp, Double -- Ø24x85mm Long |
| 22. | ZC16X01800 | [2] | CLIP | KOB |
| 23. | ZC46X22011 | [1] | CLIP | KOB |
| 24. | ZM73C10020 | [3] | BOLT,M10x20mm - Course Thread | KOBM10x1.50x20mm (Incls. Washer) |
| 25. | ZM73C10030 | [4] | BOLT,M10x30mm - Course Thread | KOBSEMS |
| 26. | ZS18C10040 | [2] | SCREW,Hex, M10 x 40mm | KOBCAP |
| 27. | ZW16P10000 | [2] | WASHER | KOBID 05 x OD 10 x Th 2.0mm |
| 3. | VH233002800A | [1] | FILTER ASSY | KOBFILTER ASSY, HINO "Engine Parts" Superseded by part number: VH23300E0201 |
| 3-1. | YN30T01002P1 | [1] | ELEMENT | KOBFILTER-ELEMENT, H/D TANK BREATHER (VH23390E0010), HINO "Engine Parts" Superseded by part number: VH23390E0011 |
| 4. | VH237811620A | [2] | PIPE | KOBFUEL, HINO "Engine Parts" Superseded by part number: VHS237811620 |
| 5. | VH965914104A | [4] | WASHER | KOBSOFT, HINO "Engine Parts" Superseded by part number: VHSL72301414 |
| 6. | VH900125233A | [2] | BANJO BOLT,25mm Dia x 38mm L | KOBBOLT, HINO "Engine Parts" Superseded by part number: VHSZ91024452 |
