纽荷兰零件查询(E235BSRNLC) - CRAWLER EXCAVATOR ASN YU05-02001 (01-016) - POWER TAKE-OFF ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
698 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF30P00005F1 | [1] | POWER TAKE-OFF ASSY | |
| 0. | YF10V00007F1 | [1] | HYDRAULIC PUMP | KOBASSY Superseded by part number: YF10V00007F3 |
| . . | YN30P00017F1 | [1] | POWER TAKE-OFF ASSY | |
| 1. | YN30P01029P1 | [1] | BRACKET | SM |
| 2. | YN30P01028F1 | [1] | COUPLING | KOBASSY Superseded by part number: YN30P01028F2 |
| 2-1. | LQ30P01003S001 | [1] | COUPLING | KOBRUBBER |
| 2-2. | YN30P01028S002 | [1] | HUB | KOB |
| 2-3. | LQ30P01003S003 | [4] | THREADED INSERT | KOBNA |
| 2-4. | LQ30P01003S004 | [4] | THREADED INSERT | KOBR |
| 2-5. | LQ30P01003S005 | [8] | SCREW | KOBCAP |
| 2-6. | YN30P01028S006 | [2] | SET SCREW | KOB |
| 2-7. | ZP26D05010 | [4] | PIN | KOBSPRING |
| 3. | ZS28C20055 | [4] | CAP,Hex Socket Head, M20 x 55mm | KOBSCREW |
| 4. | ZS18C10035 | [8] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
