| . . | YB03M00042F1 | [1] | CONTROLS, OPERATORS | |
| . . | YB03M00036F1 | [1] | CONTROL BOX ASSY, SEE FIG. 01-025 | |
| . . | YN03M01968F1 | [1] | GRIP | KOBGRIP ASSY, SEE FIG. 01-026 Superseded by part number: ZN18C14011, YN03M01503P1, YN03M01971F1, YN03M01328P2, YN03M01505P1 |
| . . | YN50E00029F1 | [1] | SWITCH INSTAL, SEE FIG. 01-027 | |
| . . | YN50M00015F1 | [1] | LEVER | KOBLEVER ASSY, PROPEL, SEE FIG. 01-029 |
| . . | YN55M00003F1 | [1] | FLOOR MAT | KOBPEDAL ASSY, SEE FIG. 01-030 Superseded by part number: YN26M00064P1 |
| . . | YN54E00008F1 | [1] | RADIO INSTAL, SEE FIG. 01-027 | |
| . . | YN12P01163F1 | [1] | CLAMP | KOBCLAMP ASSY, SEE FIG. 01-028 |
| . . | YN25M01183F1 | [1] | ARMREST | KOBARM REST, SEE FIG. 01-028 |
| . . | YB03M00031F1 | [1] | CONTROLS, OPERATORS | |
| 1. | YN03M01859P2 | [2] | SUPPORT | SM |
| 2. | YB26M00002P1 | [1] | FLOOR MAT | KOB |
| 3. | YN03M01943F1 | [1] | GUARD | SMASSY Superseded by part number: YN03M01943F2 |
| 4. | YN03M01945F1 | [1] | GUARD | SMASSY |
| 5. | YN03M01946F1 | [1] | GUARD | SMASSY |
| 6. | YB25M01010P1 | [1] | STAND | KOBSEAT Superseded by part number: YB25M01010P2 |
| 7. | YN25M01161F1 | [1] | GUIDE | SMRAIL ASSY |
| 8. | YN20M01356P1 | [1] | DIFFUSER | KOBGrille |
| 9. | ZM73C10020 | [5] | BOLT,M10x20mm - Course Thread | KOBM10x1.50x20mm (Incls. Washer) |
| 10. | ZS28C08016 | [4] | SCREW,Hex Socket Head, M8 x 16mm | KOBM08x1.25x16mm |
| 11. | ZW26K08000 | [4] | LOCK WASHER | KOBID 08 x OD 13 x Th 2.0mm |
| 12. | ZW16P08000 | [4] | WASHER | KOBID 08 x OD 17 x Th 1.6mm |
| 13. | ZS28C08020 | [4] | SCREW,Hex Socket Head, M8 x 20mm | KOBM08x1.25x20mm |
| 14. | YN02C02055P1 | [1] | TRAY | KOBAsh |
| 15. | ZM66C06016 | [9] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| 16. | ZM73C08025 | [4] | BOLT,M8x25mm - Course Thread | KOBM08x1.25x25mm (Incls. Washer) |
| 17. | YB03M01019P1 | [1] | PLATE | KOB |
| 18. | YB25M01008P1 | [1] | PLATE | KOB |
| 19. | ZM73C08016 | [2] | BOLT,M8x16mm - Course Thread | KOBM08x1.25x16mm (Incls. Washer) |
| 20. | ZM73C06016 | [2] | BOLT,M6x16mm - Course Thread | KOBM06x1.0x16mm (Incls. Washer) |
| 21. | YN20M01643P1 | [1] | SPRING | SM Superseded by part number: YN20M01643P2 |
