纽荷兰零件查询(E235BSRNLC) - CRAWLER EXCAVATOR ASN YU05-02001 (01-026) - GRIP ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
210 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN03M01968F1 | [1] | GRIP | KOBGRIP ASSY Superseded by part number: ZN18C14011, YN03M01503P1, YN03M01971F1, YN03M01328P2, YN03M01505P1 |
| 1. | YN03M01970F1 | [1] | GRIP | KOBASSY Superseded by part number: YN03M01971F1 |
| 1-1. | LF03M01005F2 | [1] | HANDLE | KOB(With 3 Switches) |
| 1-2. | YN03M01473P1 | [1] | LEVER | KOB |
| 1-3. | ZP26D05028 | [1] | PIN,5mm OD x 28mm L, Slotted | KOBSPRING |
| 2. | YN03M01971F1 | [1] | GRIP | KOBASSY |
| 3. | YN03M01505P1 | [2] | BOOT | KOB |
| 4. | YN03M01328P2 | [2] | PLATE | KOB |
| 5. | ZN18C14011 | [2] | NUT | KOB |
| 6. | YN03M01503P1 | [2] | BOOT | KOB |
