纽荷兰零件查询(E235BSRNLC) - CRAWLER EXCAVATOR ASN YU05-02001 (01-038) - PLATE INSTAL, FLOOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
425 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB03M00029F1 | [1] | PLATE INSTAL, FLOOR | |
| A1. | YB03M00022P2 | [1] | PLATE | KOBFLOOR, Serial Range: YU05-02001-YU05-02089 Superseded by part number: YB03M00065P1 |
| A1. | YB03M00022P3 | [1] | PLATE, FLOOR, Start Serial: YU05-02090 | |
| . . | YB03M00007F1 | [1] | PLATE INSTAL, FLOOR | |
| B1. | YN03M01573P1 | [2] | SILENTBLOC,110mm OD x 201mm L | KOBRUBBER |
| B2. | ZM22C10035 | [16] | BOLT | KOBSEMS |
| B3. | ZN18C16013 | [4] | NUT | KOB |
| B4. | ZW16H16000 | [4] | WASHER | KOB |
| B5. | YN03M01245P1 | [2] | ENGINE MOUNT | KOBRUBBER |
