纽荷兰零件查询(E235BSRNLC) - CRAWLER EXCAVATOR ASN YU05-02001 (01-039) - MIRROR INSTAL, P/N YF52C00006F1 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
729 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF52C00006F1 | [1] | MIRROR INSTAL | |
| 1. | YF52C00007P1 | [2] | MIRROR | KOB |
| 2. | YF52C01004P2 | [1] | STAY | KOB |
| 3. | YF52C01005P2 | [1] | STAY | KOB |
| 4. | YY52C01006P1 | [2] | SUPPORT | KOB |
| 5. | YY52C01003P1 | [2] | CLAMP | KOB |
| 6. | ZS18C08045 | [4] | SCREW,Hex, M8 x 45mm | KOBCAP |
| 7. | ZW16P08000 | [4] | WASHER | KOBID 08 x OD 17 x Th 1.6mm |
| 8. | ZN18C12010 | [4] | NUT | KOB |
| 9. | R16T0137D1 | [8] | WASHER | KOB |
| 10. | ZW16P12000 | [4] | WASHER | KOB |
| 11. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBCap |
| 12. | 2418T12346 | [2] | WASHER | KOB |
