纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (03-002) - HYD LINES, BOOM 5.65M New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
386 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 03. | YN01V00132F4 | [1] | HYDRAULIC CYLINDER | KOBCYLINDER ASSY, ARM |
| . . | YF42H00001F1 | [1] | HYD LINES,BOOM | |
| A1. | YN42H01961P1 | [2] | TUBE | KOB |
| A6. | ZX20H16170 | [1] | FLEXIBLE HOSE | KOB |
| A9. | ZD12A02100 | [4] | O-RING | KOB |
| A10. | ZD12A01800 | [6] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOB |
| A11. | 2432T2434 | [2] | CLAMP | KOB |
| A12. | ZC36X28014 | [2] | CLAMP | KOB |
| A13. | ZC26X28014 | [4] | CLAMP | KOB |
| A14. | ZS18C12055 | [6] | SCREW,Hex, M12 x 55mm | KOBCAP |
| A15. | ZW26X12000 | [8] | WASHER | KOB |
| AI6. | YX03H01046P1 | [2] | CLIP | KOB |
| A17. | ZS18C12060 | [2] | SCREW,Hex, M12 x 60mm | KOBCAP |
| . . | YN42H00209F1 | [1] | HYD LINES, CYLINDER | |
| B7. | 2432T2242 | [2] | CLAMP | KOB |
| B8. | ZS18C12050 | [2] | SCREW,Hex, M12 x 50mm | KOBCAP |
| B9. | ZS28C10030 | [16] | SCREW,Hex Socket Head, M10 x 30mm | KOBCAP |
| B10. | ZH22Z04666 | [2] | CONNECTOR | |
| B11. | ZG91S02000 | [2] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOBGREASE |
| B13. | ZD12A01600 | [2] | O-RING | KOB |
| B14. | ZD12P02600 | [4] | O-RING | KOB |
| B16. | ZE72X04000 | [1] | PLUG | KOB |
| . . | YN42H00225F1 | [1] | HYD LINES, CYLINDER | |
| C1. | YN42H01951P1 | [1] | TUBE,27.2 mm OD x 1746, 131 mm Length | KOB |
| C2. | YN42H01934D1 | [1] | HOSE | KOB |
| C3. | YN02B01030D1 | [1] | HYDRAULIC HOSE | KOB |
| C4. | YN43H01097P1 | [1] | CLAMP | KOB |
| C5. | ZH22Z04000 | [1] | HYD CONNECTOR | KOB |
| C6. | ZE13X16000 | [2] | FLANGE | KOBCLAMP, HALF |
| C8. | ZS28C12040 | [8] | SCREW,Hex Socket Head, M12 x 40mm | KOBCAP |
| C10. | ZD12P03400 | [2] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOB |
| C12. | ZW26K12000 | [4] | LOCK WASHER | KOB |
