纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (03-003) - LIGHT INSTAL (BOOM) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
636 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LC80E00004F1 | [1] | LIGHT | KOBINSTAL, BOOM |
| A1. | YW80S00001F1 | [2] | LIGHT ASSY. | KOB Superseded by part number: 2456R442F1 |
| A2. | 2416T13056 | [2] | BRACKET | KOB |
| A3. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBCap |
| A4. | 2418R323D11 | [2] | WASHER | KOB |
| A5. | 2418R323D13 | [2] | LOCK WASHER | KOB |
| . . | YF15E00001F2 | [1] | HARNESS ASSY, BOOM | |
| B2. | PY01P01043D7 | [1] | CABLE TIE,4.80mm W x 445mm L | KOB |
| B5. | YN15E01034P1 | [1] | HARNESS | KOB |
