| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| -. | 464-00091 | [-] | BAFFLE ASS'Y | |
| 1. | 2627-1285C | [1] | COVER | K1004740 |
| 1. | K1004740 | [1] | COVER | |
| 10. | S4012633 | [3] | NUT | |
| 11. | 2621-3893 | [1] | COVER | |
| 13. | 2627-1111 | [1] | COVER | |
| 2. | 621-03700 | [1] | COVER | |
| 3. | 2621-3651A | [1] | COVER | |
| 8. | S0511853 | [24] | BOLT | |
| 9. | 2114-1058D10 | [27] | WASHER |
