纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (07-020) - PUMP ASSY, GEAR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
171 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10. | YN10V00012S010 | [1] | POPPET | KOBPOPPET, (FOR F2 ONLY) |
| 11. | YN10V00012S011 | [1] | SEAT, (FOR F2 ONLY) | |
| 12. | YN10V00014S012 | [1] | RING | KOB(FOR F2 ONLY) |
| 13. | YN10V00014S013 | [1] | SPRING | KOB(FOR F2 ONLY) |
| 14. | YN10V00014S014 | [1] | SCREW | KOBADJUST, (FOR F2 ONLY) |
| 15. | YN10V00012S015 | [1] | CASE, GEAR, (FOR F2 ONLY) | |
| 16. | YN10V00012S016 | [1] | CASE,GEAR, (FOR F2 ONLY) | |
| 307. | YN10V00006S307 | [1] | POPPET | KOB(FOR F1 ONLY) Superseded by part number: YX10V00004R100 |
| 309. | YN10V00006S309 | [1] | SPRING | KOBSPRING, (FOR F1 ONLY) |
| 310. | YN10V00006S310 | [1] | SPRING | KOB(FOR F1 ONLY) |
| 311. | YN10V00006S311 | [1] | ADJUSTMENT SCREW | KOB(FOR F1 ONLY) |
| 312. | YN10V00006S312 | [1] | LOCK NUT | KOB |
| 351. | YN10V00006S351 | [1] | CASE, GEAR, (FOR F1 ONLY) | |
| 355. | YN10V00006S355 | [1] | FILTER | KOB |
| 361. | YN10V00012S361 | [1] | CASE, GEAR, (FOR F1 ONLY) | |
| 433. | YN10V00006S433 | [2] | SOCKET | KOBCAPSCREW |
| 434. | YN10V00006S434 | [2] | SOCKET | KOBCAPSCREW |
| 435. | YX46W00001S435 | [2] | SOCKET | KOBCAPSCREW |
| 466. | 2441U667S466 | [1] | PLUG | KOB |
| 467. | YN10V00006S467 | [1] | ADAPTER | KOB |
| 700. | YN10V00006S700 | [1] | RING | KOB |
| 709. | ZD12G08500 | [1] | O-RING,84.40mm ID x 90.60mm OD x 3.10mm | KOB |
| 725. | ZD12P01100 | [1] | O-RING | KOB |
| 728. | ZD12P01800 | [1] | O-RING | KOB |
| 732. | ZD12P01600 | [1] | O-RING | KOB |
| 850. | ZR26X01800 | [1] | RING | KOBRETAINING |
