沃尔沃零件查询TAMD71B; TAMD73P-A; TAMD73WJ-AIntake and Exhaust SystemInlet Manifold for Radiator CoolingEPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
890 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
471817
|
[1] |
Inlet pipe
|
|
| 2. |
965180
|
[20] |
Flange screw
|
|
| 3. |
941907
|
[20] |
Spring washer
|
|
| 4. |
424619
|
[2] |
Gasket
|
|
| 5. |
4772229
|
[1] |
Spacer
|
|
| 6. |
865069
|
[1] |
Connecting pipe
|
|
| 7. |
967825
|
[2] |
Hexagon screw
|
|
| 8. |
955894
|
[4] |
Washer
|
|
| 9. |
942283
|
[2] |
Stud
|
|
| 10. |
946330
|
[2] |
Hexagon nut
|
|
| 11. |
960629
|
[2] |
Plug
|
|
| 12. |
947282
|
[2] |
Gasket
|
|
| 13. |
960628
|
[1] |
Plug
|
|
| 14. |
947281
|
[1] |
Gasket
|
|
| 15. |
1161231
|
[1] |
Sealant
|
|
| 16. |
865128
|
[1] |
Charge air hose
|
|
| 17. |
865575
|
[2] |
Hose clamp
|
|
