纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (00-002) - SLEEVE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
917 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | ZA93S10000 | [1] | TUBE NUT | KOBSLEEVE TYPE: AMC, SLEEVE SIZE ød: 10 |
| . . | ZA93S15000 | [1] | FERRULE | KOBSLEEVE TYPE: AMC, SLEEVE SIZE ød: 15 |
| . . | ZA93S18000 | [1] | FERRULE | KOBSLEEVE TYPE: AMC, SLEEVE SIZE ød: 18 |
| . . | ZA93S22000 | [1] | RING | KOBSLEEVE TYPE: AMC, SLEEVE SIZE ød: 22 |
| . . | ZA93S28000 | [1] | FERRULE | KOBSLEEVE TYPE: AMC, SLEEVE SIZE ød: 28 |
| . . | ZA93S35000 | [1] | FERRULE | KOBSLEEVE TYPE: AMC, SLEEVE SIZE ød: 35 |
| . . | ZF93S06000 | [1] | FERRULE | KOBSLEEVE TYPE: IHARA, SLEEVE SIZE ød: 6 |
| . . | ZF93S08000 | [1] | FERRULE | KOBSLEEVE TYPE: IHARA, SLEEVE SIZE ød: 8 |
| . . | ZF93S10000 | [1] | FERRULE | KOBSLEEVE TYPE: IHARA, SLEEVE SIZE ød: 10 Superseded by part number: ZF96S10000, ZF96N10000 |
| . . | ZF93S12000 | [1] | FERRULE | KOBSLEEVE TYPE: IHARA, SLEEVE SIZE ød: 12 Superseded by part number: ZF96N12000, ZF96S12000 |
| . . | ZF93S15000 | [1] | FERRULE | KOBSLEEVE TYPE: IHARA, SLEEVE SIZE ød: 15 |
| . . | ZF93S18000 | [1] | FERRULE | KOBSLEEVE TYPE: IHARA, SLEEVE SIZE ød: 18 |
| . . | ZF93S22000 | [1] | FERRULE | KOBSLEEVE TYPE: IHARA, SLEEVE SIZE ød: 22 |
| . . | ZF93S28000 | [1] | FERRULE | KOBSLEEVE TYPE: IHARA, SLEEVE SIZE ød: 28 Superseded by part number: ZA93S28000 |
| . . | ZF93S32000 | [1] | FERRULE | KOBSLEEVE TYPE: IHARA, SLEEVE SIZE ød: 32 |
| . . | ZF93S35000 | [1] | FERRULE | KOBSLEEVE TYPE: IHARA, SLEEVE SIZE ød: 35 |
| . . | ZF93S38000 | [1] | FERRULE | KOBSLEEVE TYPE: IHARA, SLEEVE SIZE ød: 38 |
