纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (01-004) - ENGINE INSTAL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
989 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF02P00002F1 | [1] | ENGINE INSTAL | |
| 1. | YN02P01019P1 | [2] | BRACKET | KOB |
| 2. | YN02P01014P1 | [1] | BRACKET | KOB |
| 4. | YN02P01024P2 | [8] | COVER | KOB |
| 5. | YN02P01022P1 | [4] | RUBBER MOUNTING | KOB |
| 6. | YN02P01023P1 | [4] | RUBBER MOUNTING | KOB Superseded by part number: LC02P01033P1 |
| 7. | YT52S00001P1 | [1] | SENSOR,50°C to 120°C | KOBTHERMO |
| 9. | ZS18C10030 | [16] | SCREW,Hex, M10 x 30mm | KOBCAP |
| 10. | ZS18C18140 | [4] | SCREW,Hex, M18 x 140mm | KOBM18x2.50x140mm |
| 11. | ZN18C18015 | [4] | NUT | KOB |
| 12. | ZW16H18000 | [8] | WASHER | KOBID 19 x OD 36 x Th 4.5mm |
| 13. | ZW16H10000 | [16] | WASHER | KOB |
