纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (01-005[01]) - RADIATOR INSTAL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
321 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF05P00002F1 | [1] | RADIATOR INSTAL, Serial Range: YU04-00837-YU04-00894 | |
| . . | YF05P00002F2 | [1] | RADIATOR INSTAL, Start Serial: YU04-00895 | |
| A3. | ZS18C12045 | [4] | SCREW,Hex, M12 x 45mm | KOBCAP |
| A4. | ZM32C12030 | [4] | BOLT | KOBSEMS |
| A5. | ZW16H12000 | [4] | WASHER | KOB |
| A6. | LE33H01017D1 | [8] | SHIM | KOB(1.0) |
| A7. | YN05P01109P1 | [1] | SUPPORT, Start Serial: YU04-00895 | |
| A8. | 2420T2948D20 | [2] | U-BOLT | KOBM08x1.25x ID 44x 80mm Long, Start Serial: YU04-00895 |
| A9. | ZW16H08000 | [4] | WASHER | KOBID 08 x OD 18 x Th 3.2mm, Start Serial: YU04-00895 |
| A10. | ZN18C08007 | [8] | NUT | KOBM08x1.25mm, Start Serial: YU04-00895 |
| . . | YF05P00004F1 | [1] | RADIATOR GROUP | |
| B1. | YN05P01041F1 | [1] | TANK | KOBASSY, WATER, SUB |
| B1-1. | YN05P01041S1 | [1] | TANK | KOBWATER |
| B1-2. | YN05P01041S2 | [1] | CAP ASSY. | KOB Superseded by part number: YN05P01041S002 |
| B1-3. | 2427U203S6 | [1] | SWITCH | KOB |
| B4. | HX11Y05075DX | [1] | FLEXIBLE HOSE | KOB |
| B5. | NSS | [1] | NOT SERVICED SEPARATELY | CONHOSE (RADIATOR ACCESSORY) |
| B6. | YW11P01010P1 | [1] | CLIP | KOB |
| B7. | ZC16X01200 | [2] | CLIP,8mm - 15mm | KOBClamp, Hose -- Min 08 x Max 15mm |
| B8. | ZC16X06100 | [5] | CLIP | KOB |
| B9. | ZC16X07000 | [16] | CLIP | KOB |
| B10. | 2432R233D3 | [1] | CLIP | KOB |
| B15. | LC05P01118P1 | [1] | HOSE | KOB |
| B21. | ZS18C12030 | [3] | SCREW,Hex, M12 x 30mm | KOBCAP |
| B22. | ZS18C10020 | [1] | SCREW,Hex, M10 x 20mm | KOBCap |
| B23. | ZS18C10025 | [1] | SCREW,Hex, M10 x 25mm | KOB |
| B24. | ZS18C08025 | [2] | SCREW,Hex, M8 x 25mm | KOBCAP |
| B25. | ZS18C06018 | [3] | SCREW,Hex, M6 x 18mm | KOBCAP |
| B26. | ZW26X12000 | [3] | WASHER | KOB |
| B27. | ZW26X10000 | [6] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| B28. | ZW26X08000 | [2] | LOCK WASHER | KOBLock Superseded by part number: 83990583 |
| B29. | ZW26X06000 | [3] | LOCK WASHER | KOB |
| B30. | ZW16X12000 | [3] | WASHER | KOB |
| B31. | ZW16X10000 | [6] | WASHER | KOB |
| B32. | ZW16X08000 | [6] | WASHER | KOB |
| B33. | ZW16X06000 | [3] | WASHER | KOB Superseded by part number: 86588450 |
| B35. | ZM22C08020 | [4] | BOLT | KOBSEMS |
| B40. | ZS18C10045 | [4] | SCREW,Hex, M10 x 45mm | KOBCAP |
| B43. | ZS18C08020 | [4] | SCREW,Hex, M8 x 20mm | KOB |
