纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (01-007) - CLEANER ASSY, AIR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
233 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN11P00019F1 | [1] | CLEANER ASSY,AIR | |
| 1-3. | YN11P00001S003 | [1] | COVER | KOBASSY |
| 1-4. | 2446U242S4 | [1] | VALVE | KOBASSY |
| 1-5. | YR11P00008S005 | [1] | INDICATOR | KOB Superseded by part number: LV11P01017F1 |
| 1-6. | YN11P00001S006 | [1] | O-RING | KOB |
| 2. | YN11P01059P1 | [1] | HOSE | KOBAIR |
| 5. | ZC16X11000 | [4] | CLIP | KOB |
| 6. | ZC16X09100 | [1] | CLIP | KOB |
| 7. | ZC16X06700 | [1] | CLIP,58mm - 76mm | KOB |
| 8. | ZM22C10025 | [4] | BOLT | KOBSEMS |
