纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (01-009) - MUFFLER ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
479 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF12P00001F1 | [1] | MUFFLER ASSY | |
| 2. | YN12P01076P1 | [1] | TUBE | KOBEXHAUST |
| 3. | YN12P01044P1 | [1] | BRACKET | KOB |
| 5. | YN12P01023P1 | [1] | CLAMP,60.5mm - 65mm | KOBAssembly |
| 6. | HR91C08000GK | [2] | CLAMP | KOBU-BOLT |
| 7. | HX11Y07090DX | [1] | FLEXIBLE HOSE | KOB Superseded by part number: HX11Y07100DX |
| 9. | ZS18C10020 | [3] | SCREW,Hex, M10 x 20mm | KOBCap |
| 10. | ZS18C10025 | [6] | SCREW,Hex, M10 x 25mm | KOB |
| 11. | ZS18C10030 | [2] | SCREW,Hex, M10 x 30mm | KOBCAP |
| 12. | ZS18C10035 | [2] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 13. | ZN18C08007 | [8] | NUT | KOBM08x1.25mm |
| 14. | ZN18C10008 | [2] | NUT | KOBM10x1.50mm |
| 15. | ZW16X10000 | [13] | WASHER | KOB |
| 16. | ZW26X10000 | [11] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 17. | ZC16X01200 | [1] | CLIP,8mm - 15mm | KOBClamp, Hose -- Min 08 x Max 15mm |
| 19. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOB |
| 20. | ZW16X08000 | [2] | WASHER | KOB |
| 8. | ME088841 | [1] | GASKET, MITSUBISHI E/G PARTS NUMBER | |
