纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (01-016) - CONTROL ASSY, ENGINE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
211 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF11M00002F1 | [1] | CONTROL ASSY, ENGINE | |
| 3. | YN11M01186F1 | [1] | LEVER | KOBASSY |
| 3-1. | YN11M01188P1 | [1] | PLATE | KOB |
| 3-2. | YN11M01190F1 | [1] | LEVER | KOBASSY |
| 3-2A. | YN11M01189P1 | [1] | LEVER | KOB |
| 3-2B. | 2405R312D1215 | [1] | BUSHING | KOB Superseded by part number: 2405R61D2 |
| 3-3. | YN11M01210P1 | [1] | SPRING | KOB |
| 3-4. | ZW16X12000 | [1] | WASHER | KOB |
| 3-5. | ZR16X01200 | [1] | RING | KOBRETAINING |
| 4. | YN20S00002F1 | [1] | MOTOR | KOBASSY, GOVERNOR |
| . . | YN20S00002F1R | [1] | REMAN-ELECTRIC MOTOR | KOBE235SR BTW YF04-01513 - YF04-01758,E235SRLC BTW YU04-00837 - YU04-01417 |
| . . | YN20S00002F1C | [1] | CORE-ELECTRIC MOTOR | KOBReturn Number |
| 5. | LQ11M01053P1 | [1] | ROD | KOB |
| 6. | HR37C08000G1 | [1] | BALL JOINT | KOBReplaces 2425R227D2, M08x1.25x45.5mm Long |
| 7. | ZN18C08007 | [3] | NUT | KOBM08x1.25mm |
| 8. | ZM22C10025 | [4] | BOLT | KOBSEMS |
| 9. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 10. | YN03M01159P1 | [1] | GROMMET | KOB |
| 11. | YN11M01114P2 | [1] | PIN | KOB Superseded by part number: ZP45X06018 |
| 12. | ZS28C06020 | [1] | SCREW,Hex Socket Head, M6 x 20mm | KOBCAP |
| 13. | ZW26X06000 | [3] | LOCK WASHER | KOB |
| 14. | ZS18C06016 | [2] | SCREW,Hex, M6 x 16mm | KOBCAP |
| 15. | YN11M01013D1 | [1] | BALL JOINT | KOB Superseded by part number: HR37D08000G1 |
| 16. | 2419R9D1 | [1] | COTTER PIN | KOBSNAP |
| 17. | 2420T7359 | [1] | NUT | KOB(LEFT-HAND) |
| 20. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBCap |
| 22. | ZS28C10030 | [3] | SCREW,Hex Socket Head, M10 x 30mm | KOBCAP |
| 24. | YN11M01102P1 | [1] | PLATE | KOB |
| 26. | ZW26X08000 | [4] | LOCK WASHER | KOBLock Superseded by part number: 83990583 |
| 27. | ZS18C08030 | [2] | SCREW,Hex, M8 x 30mm | KOBCAP |
| 28. | LC11M01034P1 | [1] | ROD | KOBEND |
| 29. | ZN18C06005 | [1] | NUT | KOB |
| 30. | YT11M01012P1 | [1] | GROMMET | KOB Superseded by part number: YR03M01293P1 |
| 31. | 2432T4615 | [1] | LABEL | KOB |
| 32. | ZM22C08020 | [3] | BOLT | KOBSEMS |
