纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (01-015) - TANK ASSY, HYD New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
588 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF33H00002F4 | [1] | TANK ASSY, HYD | |
| A2-1. | YN50V00002S001 | [1] | STRAINER ASSY. | KOB |
| A2-3. | ZN11C10008 | [1] | NUT | KOB Superseded by part number: ZN18C10008 |
| A2-7. | YW50V00004S007 | [1] | BOLT | |
| A3. | YT33H01028P1 | [1] | LABEL | KOB, Serial Range: YU04-00837-YU04-00969 Superseded by part number: YF33H01020P1 |
| A3. | YF33H01020P1 | [1] | LABEL | KOBLABEL, Start Serial: YU04-00970 |
| A5. | YN58S00009F1 | [1] | GAUGE | KOBASSY, LEVEL |
| A5-1. | NSS | [2] | NOT SERVICED SEPARATELY | CONBLOCK |
| A6. | ZD11G20000 | [2] | O-RING,5.7mm Thk x 199.3mm ID, 70 Duro | KOB |
| A9. | YN57V00002F4 | [1] | BREATHER ASSY. | KOB Superseded by part number: YN57V00010F1 |
| A9-1. | 2446U260S1 | [1] | BODY | KOBASSY |
| A9-4. | 2446U260S5 | [1] | NUT | KOB |
| A9-6. | 2446U260S8 | [1] | PACKING | KOB |
| A9-7. | YN57V00002S007 | [1] | IDENTITY PLATE | KOBCAUTION |
| A9-10. | YN57V00002S010 | [1] | ELEMENT | KOB Superseded by part number: YN57V00010S002 |
| A9-11. | YN57V00002S011 | [1] | COVER | KOB |
| A9-12. | YN57V00002S012 | [1] | CAP | KOB |
| A10. | ZS28C06016 | [4] | SCREW,Hex Socket Head, M6 x 16mm | KOBCAP |
| A11. | ZW26K06000 | [4] | LOCK WASHER | KOB |
| A12. | ZE72X08000 | [1] | PLUG | KOB |
| A13. | ZS18C10025 | [12] | SCREW,Hex, M10 x 25mm | KOB |
| A14. | ZW16X10000 | [12] | WASHER | KOB |
| A18. | YN52V01008F4 | [1] | ELEMENT | KOBFILTER Superseded by part number: YN52V01016F4 |
| A18-2. | YN52V01008S002 | [1] | PLATE | KOB |
| A18-3. | YN21V00015P1 | [1] | CHECK VALVE | KOB |
| A18-4. | ZD11G09000 | [1] | O-RING,89.40mm ID x 95.60mm OD x 3.10mm | KOB |
| A18-5. | YN52V01008S005 | [1] | PACKING | KOB |
| A18-6. | LC33H01009P1 | [1] | SPRING | KOB |
| A18-10. | YN52V01013P1 | [2] | HYDRAULIC OIL FILTER | KOBFILTER Superseded by part number: YN52V01021P1 |
| . . | YN52V01008R200 | [1] | ELEMENT | KOBKIT CONSISTS OF ITEM A6, A18-4, A18-5 & A18-10(2) Superseded by part number: YN52V01016R210 |
| . . | YN33H00019F1 | [1] | TANK INSTAL.HYD | |
| B1. | ZS18C16040 | [4] | SCREW,Hex, M16 x 40mm | KOBCAP |
| B2. | ZW16H16000 | [4] | WASHER | KOB |
| B3. | LE33H01017D1 | [3] | SHIM | KOB(1.0) |
| B4. | YN52S00023P1 | [1] | PROXIMITY SWITCH | KOBLEVEL |
| B5. | YN33H01052P1 | [1] | SEAL | KOB |
