纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (01-021) - HYD LINES, UPP (SUCTION, DELIVERY) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
830 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF30H00001F1 | [1] | HYD LINES, PUMP | |
| 5. | ZE13X12000 | [4] | CLAMP | KOBHALF |
| 6. | LC52S00012P1 | [2] | SENSOR | KOBPRESS (H. P.) Superseded by part number: YY52S00033F1 |
| 6-1. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 7. | PY01P01043D3 | [2] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 8. | ZC16X09100 | [4] | CLIP | KOB |
| 9. | ZD11G07500 | [1] | O-RING,74.40mm ID x 80.60mm OD x 3.10mm | KOB |
| 10. | ZD12P02600 | [2] | O-RING | KOB |
| 11. | ZS28C12045 | [4] | SCREW,Hex Socket Head, M12 x 45mm | KOBCAP |
| 12. | ZS18C10035 | [8] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 13. | ZW26K12000 | [4] | LOCK WASHER | KOB |
| 14. | ZW26X10000 | [8] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 15. | ZH32X12000 | [1] | 90 ELBOW,Male, 30° Fl, PF 3/4" x PF 3/4", O-Ring | KOBELBOW |
| 15-1. | ZD12P02400 | [1] | O-RING | KOB |
| 16. | YN64H01018P1 | [1] | GROMMET | KOB |
| 27. | ZE72X04000 | [2] | PLUG | KOB |
| 27-1. | ZD12P01100 | [1] | O-RING | KOB |
