纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (01-020) - VALVE INSTAL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
128 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN64H00143F1 | [1] | VALVE | KOBINSTAL |
| A1. | YN30V00084F1 | [1] | CONTROL VALVE | KOBASSY, (ADD-ON) |
| A2. | ZS23C12100 | [4] | CAPSCREW,Hex Socket Head, M12 x 100mm | KOBSCREW CAP |
| . . | YN64H00062F2 | [1] | VALVE INSTAL | |
| B3. | ZS18C12035 | [2] | SCREW,Hex, M12 x 35mm | KOBCAP |
| B4. | ZS18C12060 | [3] | SCREW,Hex, M12 x 60mm | KOBCAP |
| B5. | ZW16H12000 | [10] | WASHER | KOB |
| B6. | ZN18C12010 | [3] | NUT | KOB |
| B7. | ZS18C12050 | [2] | SCREW,Hex, M12 x 50mm | KOBCAP |
