纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (01-024[02]) - HYD LINES, UPP (RETURN) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
576 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF32H00001F1 | [1] | HYD LINES, RETURN | |
| 3. | 2444R596D3 | [1] | ELBOW | KOB |
| 8. | ZX22M08100 | [1] | HOSE | KOB |
| 9. | ZX32M08210 | [1] | FLEXIBLE HOSE | KOB |
| 10. | ZG15F05100 | [1] | COUPLING | KOB |
| 10-3. | ZG15G05100 | [2] | GASKET,50.85mm ID x 67.20mm OD | KOB Superseded by part number: R44P0089D4S3 |
| 11. | R44P0089D8 | [2] | ELASTIC JOINT,101mm ID x 148.8mm OD x 165.1mm L | KOBCOUPLING |
| 11-3. | R44P0089D8S3 | [2] | GASKET | KOB |
| 12. | ZG15F04300 | [4] | COUPLING | KOB |
| 12-3. | ZG15G04300 | [2] | GASKET,43mm ID x 58mm OD | KOB Superseded by part number: R44P0089D7S3 |
| 13. | YN21V00008F1 | [1] | HYDRAULIC VALVE | KOBASSY, CHECK Superseded by part number: YN21V00013F1 |
| 14. | YN21V00007F1 | [1] | CHECK VALVE | KOBASSY |
| 20. | ZH42X12016 | [1] | 45 ELBOW,Male, 30° Fl, PF 3/4" x PF 1", O-Ring | KOB |
| 20-1. | ZD12P02900 | [1] | O-RING | KOB |
| 21. | ZE72X16000 | [1] | PLUG | KOB |
| 23. | 2444Z2360 | [1] | TEE | KOB |
| 23-1. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 24. | HH55X12012G3 | [1] | TEE | KOB |
| 24-1. | ZD12P02400 | [1] | O-RING | KOB |
| 25. | 2432T5299 | [2] | CLAMP | KOB |
| 26. | YN02B01031D2 | [2] | SPACER | KOB |
| 27. | 2414Z199D100 | [1] | GUARD | KOBHOSE |
| 28. | 2420T2948D20 | [6] | U-BOLT | KOBM08x1.25x ID 44x 80mm Long |
| 29. | ZC46X31014 | [1] | CLIP | KOB |
| 30. | YW05P01025P1 | [1] | CLIP | KOB |
| 31. | ZD11G04500 | [1] | O-RING,44.40mm ID x 50.60mm OD x 3.10mm | KOB |
| 33. | ZS18C10055 | [2] | SCREW,Hex, M10 x 55mm | KOBCAP |
| 35. | ZS18C12025 | [5] | SCREW,Hex, M12 x 25mm | KOBCAP |
| 36. | ZS18C12030 | [5] | SCREW,Hex, M12 x 30mm | KOBCAP |
| 37. | ZS18C12035 | [4] | SCREW,Hex, M12 x 35mm | KOBCAP |
| 38. | ZW16H08000 | [12] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 39. | ZW16H10000 | [8] | WASHER | KOB |
| 40. | ZW16H12000 | [18] | WASHER | KOB |
| 41. | ZN18C08007 | [24] | NUT | KOBM08x1.25mm |
| 42. | ZN18C10008 | [1] | NUT | KOBM10x1.50mm |
| 43. | ZN18C12010 | [2] | NUT | KOB |
| 44. | ZS18C12065 | [1] | SCREW,Hex, M12 x 65mm | KOBCAP |
| 45. | YN32H01010P1 | [1] | CLAMP | KOB |
| 47. | ZC46X38014 | [1] | CLIP | KOB |
| 48. | YN03H01074P1 | [1] | BUSHING | KOB |
| 50. | YN32H01066P1 | [1] | CLAMP | KOB |
| 51. | ZS18C12060 | [1] | SCREW,Hex, M12 x 60mm | KOBCAP |
| 53. | YN20M01046DC | [1] | TUBE,22.10mm ID x 27.00mm OD x 1600.00mm | KOB |
| 54. | ZS18C10025 | [1] | SCREW,Hex, M10 x 25mm | KOB |
