纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (06-001[01]) - NAME PLATE INSTAL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
178 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB22T00045F1 | [1] | NAME PLATE INSTAL (REQUIRED) | |
| 1. | ZL11N02604 | [1] | LABEL | KOB |
| 2. | ZL11N00404 | [1] | LABEL | KOB |
| 3. | 2432T3972 | [1] | LABEL | KOBUSE ONLY NON ANINE ANTI-FREEZE |
| 4. | ZL11N05204 | [1] | LABEL | KOB |
| 5. | ZL11N05104 | [1] | DECAL | KOBLABEL |
| 6. | YN20T01356P1 | [1] | DECAL | KOBLABEL |
| 7. | YN20T01213P1 | [1] | LABEL | KOB |
| 8. | YN20T01355P1 | [1] | LABEL | KOB |
| 9. | ZL11M04116 | [2] | LABEL | KOB |
| 10. | ZL11N01104 | [1] | LABEL | KOB |
| 11. | 2432T6179 | [2] | CAUTION DECAL | KOBDecal, Recycle |
| 12. | ZL11N00504 | [1] | LABEL | KOB |
| 13. | YN20T01097P1 | [1] | LABEL | KOBFILLED WITH ANTI-FREEZE |
| 14. | YB20T01005P1 | [1] | LABEL | KOB |
| 15. | YN20T01363P1 | [1] | LABEL | KOB |
| 16. | YT20T01112P1 | [4] | LABEL | KOB |
| 18. | 4020Z64 | [4] | RIVET | KOBOD 5.0 x 6.0mm Long Superseded by part number: 2420P623D7 |
| 19. | PM20T01054P1 | [1] | TYPE PLATE | KOBPLATE, NUMBER |
| 20. | 2432T6142 | [2] | LABEL | KOB |
| 21. | 2432T6139 | [4] | LABEL | KOB Superseded by part number: YN20T01818P1 |
| 23. | 2427Z1432 | [2] | SHEET | KOBLABEL |
| 24. | 2427Z329 | [2] | SHEET | KOBLABEL |
| . . | YB22T00045F3 | [1] | NAME PLATE INSTAL | |
