凯斯零件查询(LB324S) - BALER (9/12-) (90.118.010) - LADDER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
658 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84548179
|
[1] |
LADDER
|
ZED
|
| 2. |
84246147
|
[1] |
LADDER
|
ZED
|
| 3. |
84225825
|
[1] |
BRACKET
|
ZED
|
| 4. |
84394843
|
[1] |
MAGNET,M6, 47mm OD
|
ZED
|
| 5. |
140045
|
[4] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 6. |
100016
|
[4] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 7. |
120041
|
[2] |
CARRIAGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 8. |
43138
|
[2] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8
|
NH
|
| 9. |
100037
|
[2] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 10. |
86507486
|
[3] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 11. |
322358
|
[3] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 12. |
9706690
|
[3] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 13. |
322356
|
[1] |
BELLEVILLE WASHER,M5 Bolt Size x 12mm OD x 1.85mm Thk
|
ZED
|
| 14. |
9706755
|
[1] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
| 15. |
120103
|
[1] |
BOLT,M8 x 1.25 x 16mm, Cl 8.8
|
NH
Superseded by part number: 16043224
|
| 16. |
401502
|
[1] |
ANTI-SKID STRIP
|
ZED
L = 0.44 M
|
