凯斯零件查询(LB324S) - BALER (9/12-) (90.118.050) - LIGHT ARMS, REAR Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
637 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47371232
|
[1] |
PROFILE
|
ZED
, Serial Range: -C071 Superseded by part number: 47470841
|
| 1. |
47470841
|
[1] |
PROFILE
|
ZED
, Serial Range: -F072144
|
| 1. |
47908425
|
[1] |
PROFILE
|
ZED
, Start Serial: D145
|
| 1. |
47427030
|
[1] |
PROFILE
|
ZED
,, Serial Range: -F044071 Superseded by part number: 47470841
|
| 2. |
47371231
|
[1] |
PROFILE
|
ZED
, Serial Range: -C071 Superseded by part number: 47470839
|
| 2. |
47470839
|
[1] |
PROFILE
|
ZED
, Serial Range: -F072144
|
| 2. |
47908373
|
[1] |
PROFILE
|
ZED
, Start Serial: D145
|
| 2. |
47427028
|
[1] |
PROFILE
|
ZED
,, Serial Range: -F044071 Superseded by part number: 47470839
|
| 3. |
746294
|
[2] |
LAMP REFLECTOR
|
NH
Superseded by part number: 80746294, 80746294, BER746294
|
| 4. |
120044
|
[6] |
CARRIAGE BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 5. |
140046
|
[6] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 6. |
9706685
|
[6] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 7. |
84429678
|
[4] |
RIVET
|
ZED
|
| 8. |
322356
|
[4] |
BELLEVILLE WASHER,M5 Bolt Size x 12mm OD x 1.85mm Thk
|
ZED
|
| 9. |
435895
|
[4] |
REFLECTOR,80mm OD, Orange
|
NH
|
| 10. |
9839002
|
[2] |
EXTERNAL REFLECTOR
|
ZED
|
| 11. |
84333970
|
[1] |
HOLDER
|
ZED
, Serial Range: -C084
|
| 12. |
86547710
|
[1] |
EMBLEM
|
ZED
, Serial Range: -C084
|
| 13. |
120100
|
[2] |
BOLT,M6 x 20mm, Cl 8.8
|
NH
, Serial Range: -C084
|
| 14. |
412649
|
[2] |
BELLEVILLE WASHER,M6 Bolt Size x 18mm OD x 1.4mm Thk
|
ZED
, Serial Range: -C084
|
| 15. |
9706755
|
[2] |
NUT,M6, Cl 8
|
NH
, Serial Range: -C084 Superseded by part number: 86500688
|
