| . . | YF06H00003F1 | [1] | CONTROL LINES, MAIN (BOOM & ARM SAFETY) | |
| . . | YF06H00003F2 | [1] | CONTROL LINES, MAIN (BOOM SAFETY) | |
| 1. | LC52S00011P1 | [1] | SENSOR | KOBPRESS (L.P.) Superseded by part number: LC52S00019P1 |
| 1-1. | ZD12P01100 | [1] | O-RING | KOB |
| 2. | ZH22X04006 | [6] | HYD CONNECTOR | KOB |
| 3. | ZH22X06000 | [6] | HYD CONNECTOR | KOB(FOR F1 ONLY) |
| 4. | 2444Z2891 | [3] | HYD CONNECTOR | KOB(FOR F1 ONLY) |
| 5. | 2444T2524 | [1] | HYD CONNECTOR | KOB |
| 6. | YN21V00005F2 | [2] | CHECK VALVE | KOBASSY, CHECK |
| 7. | 2444Z3711 | [2] | HYD CONNECTOR | KOB |
| 8. | YN06H01006P1 | [1] | CONNECTION | KOB |
| 9. | YN06H01017P1 | [2] | HYD CONNECTOR | KOB |
| 10. | ZH32X04000 | [8] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOBELBOW |
| 11. | ZH32X04006 | [8] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 3/8", O-Ring | KOB |
| 12. | ZH32X06000 | [7] | 90 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 13. | 2444Z3155 | [2] | 90 ELBOW,PF 3/8" Fem x PF 3/8" Male | KOB Superseded by part number: YT42H01128P1 |
| 14. | HH55Q04004G1 | [2] | TEE,1/4" ORB x 1/4" JIC x 1/4" JIC | KOB |
| 15. | HH55Q06006G1 | [8] | TEE | KOB |
| 16. | YN64H01048P1 | [1] | TEE,90°, PF 3/8" x PF 3/8", O-Ring | KOB(FOR F1 ONLY) |
| 18. | PU13E01010D8 | [1] | RIGID TUBE | KOB |
| 19. | 2444R1120D100 | [1] | HOSE | KOB |
| 20. | 2444R1120D040 | [1] | HOSE | KOB |
| 22. | 2420R349D046 | [1] | FLEXIBLE HOSE | KOBHOSE Superseded by part number: 2420R349D050 |
| 23. | 2420R349D050 | [1] | HOSE,500.00 mm | KOB |
| 24. | 2420R349D064 | [1] | FLEXIBLE HOSE | KOB Superseded by part number: HX21E04065DX |
| 25. | 2420R349D070 | [1] | HOSE,700.00 mm | KOB |
| 26. | 2420R349D090 | [1] | HOSE,6.35mm ID x 900mm L | KOB |
| 27. | 2420R349D100 | [1] | HOSE | KOB Superseded by part number: HX21E04100DX |
| 28. | YN21V00005F4 | [1] | CHECK VALVE | KOBASSY |
| 30. | ZH22X04000 | [1] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB |
| 31. | ZH42X04006 | [1] | 45 ELBOW,Male, 30° Fl, PF 1/4" x PF 3/8", O-Ring | KOB |
| 32. | ZH42X06000 | [2] | 45 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOB45 |
| 34. | PU13E01002D9 | [1] | TUBE | KOB |
| 35. | PY01P01043D6 | [1] | CABLE TIE,4.80mm W x 383mm L | KOB |
| 36. | 2444Z2336 | [1] | HYD CONNECTOR | KOBTEE |
| 37. | 2444R596D1 | [1] | ELBOW | KOB |
