纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (05-002[01]) - CONTROL LINES, REMOTE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
944 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF64H00007F1 | [1] | CONTROL LINES, VALVE (BOOM & ARM SAFETY) | |
| . . | YF64H00007F2 | [1] | CONTROL LINES, VALVE (BOOM SAFETY) | |
| 4. | 2420R537D200 | [1] | HOSE,9.60mm ID x 2000mm L | KOB |
| 5. | 2420R537D210 | [1] | HOSE,9.53mm ID x 2100mm L | KOB |
| 6. | 2420R537D270 | [1] | FLEXIBLE HOSE,9.60mm ID x 2700mm L | KOB |
| 8. | PY01P01043D8 | [14] | CABLE TIE,102mm L | KOB(FOR F1 ONLY) |
| 9. | ZH22F06000 | [2] | CONNECTION | KOB(FOR F1 ONLY) |
| 10. | ZH22X06000 | [3] | HYD CONNECTOR | KOB(FOR F1 ONLY) |
| 11. | HH25R06006GC | [1] | HYD CONNECTOR | KOB |
| 12. | 2444Z3546 | [1] | ELEC CONNECTOR | KOB |
| 13. | ZE72X06000 | [1] | PLUG | KOB(FOR F1 ONLY) |
| 14. | 2414Z199D045 | [1] | GUARD | KOBHOSE, (FOR F1 ONLY) |
| 15. | PU13E01010D7 | [2] | TUBE | KOB |
| 16. | PY01P01043D3 | [4] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 17. | 2414Z199D100 | [1] | GUARD | KOBHOSE, (FOR F1 ONLY) |
| 22. | 2418Z1333D5 | [2] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 400mm Length | KOB |
